In-Plane Crushing of Square Honeycomb Cores, Part I: Mechanical Behaviors

Abstract:

Mechanical behaviors of square honeycombs cores (SHCs) are investigated by using the finite element (FE) simulations under the in-plane dynamic crushing loadings. With the increasing impact velocities, different deformation modes are observed. The force-displacement curves include four regimes with distinct characteristics. The plateau stresses are calculated for the SHCs with different configuration parameters. The dynamic plateau stress is the sum of the static plateau stress and the dynamic enhancement due to the inertia effect. The static plateau stress is proportional to the relative density of SHCs. The dynamic enhancement stress is proportional to the square of impact velocity and the relation coefficient depends on the configuration parameters. The empirical formulas of dynamic plateau stress in terms of configuration parameters and impact velocity are given.

• Periodical: Applied Mechanics and Materials (Volumes 170-173)
• Pages: 3220-3223
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.170-173.3220
• Online since: May 2012
• Authors: De Qiang Sun, Wen Ting Cao, Meng Cai
• Keywords: Critical Velocity of Mode Transition, Deformation Mode, In-Plane Crushing, Plateau Stress, Square Honeycomb Cores

References

[1] A.J. Wang, and D.L. McDowell: J. Eng. Mater. Technol. Vol. 126(2004), p.137.

[2] H.X. Zhu and N.J. Mills: Int. J. Solids Struct. Vol. 37(2000), p.1931.

[3] D. Sun and W. Zhang: Comp. Struct. Vol. 91(2009), p.168.

[4] Y. Liu and X.C. Zhang: Int. J. Impact Eng. Vol. 36(2009), p.98.

[5] X.M. Qiu, J. Zhang and T.X. Yu: Int. J. Impact Eng. Vol. 36(2009), p.1223.

[6] X.M. Qiu, J. Zhang and T.X. Yu: Int. J. Impact Eng. Vol. 36(2009), p.1231.

[7] G.X. Peng: Transporting Package (Printing Press, Beijing 1999) (in Chinese).

[8] L.J. Gibson and M.F. Ashby: Cellular solids: structure and properties (Cambridge University Press, Cambridge 1997).

[9] S.R. Reid and C. Peng: Int. J. Impact Eng. Vol. 19(1997), p.531.

[10] Q.C. Wang and Z.J. Fan: Mech. Eng. Vol. 25(2003), p.20. (In Chinese)
