X-Ray CT Image Segmentation of Asphalt Concrete Based on Fuzzy C-Means

Abstract:

This study focuses on the threshold segmentation algorithm to obtain the real microstructure of asphalt concrete based on digital image technique, the perlite powder which was a kind of low-density material was put in the asphalt concrete to enhance the density contrast, three different specimens in which added different contents of perlite powder were compacted, and then the asphalt concrete specimens were scanned using x-ray CT to capture the gray images that reflect the density differences of the three constituents such as aggregates, mastic and voids, the CT images were converted to be the histograms. Furthermore, the FCM (Fuzzy C-Means) was demonstrated that it could be utilized to choose proper threshold values and segment images exactly, according to the double peak conditions of the three different histograms, the double peak condition for AC-13 is the best among the three types, a similar double peak features between AK13 and SMA-13 were observed. The results shows that the different contents of perlite powder added in the asphalt concrete can form different double peaks. This is another new method to segment the three constituents of the asphalt concrete exactly.

• Periodical: Applied Mechanics and Materials (Volumes 170-173)
• Pages: 3444-3448
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.170-173.3444
• Online since: May 2012
• Authors: Jian Jun Wei, Hai Bin Li, Cheng Wan
• Keywords: Asphalt Concrete, FCM Segmentation, Histogram, X-Ray CT

References

[1] Yiqiu Tan, Xiaolin Li, Xinye Zhou. Interactions of Granite and Asphalt Based on the Rheological Characteristics. Journal of Materials in Civil Engineering, 22(8):820-825, 2010.

DOI: 10.1061/(asce)mt.1943-5533.0000014

[2] E. Masad, B. Muhunthan, N. Shashidhar, T. Harman．Quantifying laboratory compaction effects on the internal structure of asphalt concrete.Transportation Research Record. Washington D C,1999．

DOI: 10.3141/1681-21

[3] L. B. Wang, Y. Wang, L. Mohammad,T. Harman. Voids distribution and performance of asphalt concrete. International Journal of Pavements, 1(3): 22-33, 2002.

[4] Wenliang Wu, Duanyi Wang, Xiaoning Zhang, Zhi Li. Research on voids in coarse aggregate of asphalt concretes with digital image processing and probability statistics. Journal of Tongji University, 38(12): 1792-1794, 2010.

[5] Yuehua Duan, Xiaoning Zhang, Hongjie Li, Wenliang Wu, Cheng Wan. Three-dimensional digital representation of aggregates on asphalt concrete using X-ray computed tomography images. Journal of Computational Information Systems, 6(13): 4391-4400, 2010.

[6] Yiqiu Tan, Huining Xu, Xiaoming Li. Is Normal Distribution the Most Appropriate Statistical Distribution for Volumetric Properties in Asphalt Concretes? Journal of Testing and Evaluation, 27(5):458-478, 2009.

DOI: 10.1520/jte000375

[7] Yanling Li, Yi Sheng. Fuzzy C-means algorithm based on the spatial information for image segmentation. Journal of Huazhong University of Science and Technology(Nature Science Edition),37(6):56-59.
