Square Steel Pipe Regeneration Block Party of a Concrete Column Nonlinear Finite Element Analysis

Abstract:

By testing the Axial compression performance of the Block of concrete short columns regenerated by No rib and steel ribbed thin-walled square and simulating the finite element program ANSYS calculation ,we are going to reveal the square steel tube regeneration block of mixed component axial compressive deformation and failure mode ,and analyze the longitudinal force and the strain relationship of the longitudinal direction and the horizontal direction as well as the effect on forcing performance and failure mode of specimen played by the combined concrete force of fresh concrete. The results showed that the main failure mode of specimen is crushed drum-type damage. In the elastic state, all the strain growth in the middle section and the corner is self and growth of longitudinal strain of the two is relatively consistent. On damaging stage, the specimen without ribs is softened, while the specimen with ribs shows a feature of stiffening. The results of finite element analysis fit the test results well.

• Periodical: Applied Mechanics and Materials (Volumes 174-177)
• Pages: 1333-1338
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.174-177.1333
• Online since: May 2012
• Authors: Bai Shou Li, Yue Hong Li, Ping Zhang
• Keywords: ANSYS Analysis, Failure Mode, Regenerated Block, Stress-Strain Relation, Thin-Walled Rectangular Pipe

References

[1] Jian-zhuang Xiao.RecyclcedConcrete[M].Beijing:ChinaArchitecture&BuildingPress,2008:324. In Chinese

[2] Tao Feng.A rib of concrete filled steel tubular short column thin-walled party axial compressive load performance finite element analysis [D]. Master thesis, central south university, 2010. In Chinese

[3] Cai J,He Z Q.Axial load behavior ofsquare CFT stub column with binding bars[J].Journal of Constructional Steel Research,2006,62(5):472~483.

DOI: 10.1016/j.jcsr.2005.09.010

[4] Jian Cai, Qiang Hezhen, Xing Chen.With binding bars rectangular steel tube concrete short columns axial compression properties test [J]. Industrial building, inc (3) : 75 ~ 80. In Chinese

[5] Huang C S,Yeh Y K,Liu G Y,et al.Axial load behavior of stiffened concrete-filled steel columns.Journal of Structural Engineering,ACSE,2002,128(9):1222~1230.

DOI: 10.1061/(asce)0733-9445(2002)128:9(1222)

[6] Tong Zhongshan.Steel tube concrete structure (second edition) [M]. Beijing: tsinghua university press,2003. In Chinese
