Role of Temperature and Flow in Biomass Transporting in Porous Media

Abstract:

Underground water source heat pumps system is an underground geothermal technology that extracts underground water as a lower temperature heat source, and recharged into the same aquifer after heat exchanger. During the recharging process, not only external microorganisms such as bacteria but also a variety of contaminants ( for example carbon sources, nitrogen sources, the growth inhibitors/promoters and so on) would get into the aquifer to affect the aquifer's living environment for microbial, which would affect the quality of underground water directly or indirectly. Not only that, the extraction and injection of underground hot water would cause the redistribution of temperature, which would then affect the growth of microorganisms as a key affecter. And the biomass would be transported by seepage flow in way of advection and conduction mainly. Based on the background of underground water source heat pumps system, the coupling of three-field (temperature-hydraulic-microbial) is analyzed, and a corresponding coupled THB model is obtained. Taking Escherichia coli as target organisms in the aquifer, the distribution of biomass various with time and space are obtained respectively. The temperature and advection sensitivity of microbial concentration is also acquired. It is showed that the growth of microbial plays a great role in the process of its transportation, and the concentration of microbial would increase significantly when the local temperature increased or the convection strength decreased while other effects stay the same.

• Periodical: Applied Mechanics and Materials (Volumes 178-181)
• Pages: 80-87
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.178-181.80
• Online since: May 2012
• Authors: Jing Jing Huang, Cheng Yuan Zhang
• Keywords: Biomass Distribution, Coupled THB Model, Microbial Growth, Porous Medium

References

[1] Long Ni. Operation performance research on heat source/sink well of groundwater heat pump with pumping & recharging in the same well. Harbin Institute of Technology.2007-06, 45-71.

[2] Yuandong Zhang, Jiahua Wei, Yu Li, et.al. Simulation of changes in geo-temperature field due to energy abstraction from underground aquifers [J]. Journal of Tianjin University (2006). Vol.39, 908-912.

[3] Xiaobo Wu. Development of ground waterloop for ATES and groundwater source heat pump systems [J]. HV&AV(2004), Vol.34, 19-22.

[4] Stewart W. Taylor, Peter R. Jaffe. Biofilm Growth and the Related Changes in the Physical Properties of a Porous Medium: 1.Experimental Investigation [J]. Water Resources Research (1990). Vol26, 2153-2159.

DOI: 10.1029/90wr00847

[5] Stewart W. Taylor, Peter R. Jaffe. Biofilm Growth and the Related Changes in the Physical Properties of a Porous Medium: 2.Permeability [J]. Water Resources Research (1990). Vol. 26, 2161-2169

DOI: 10.1029/wr026i009p02161

[6] T.P. Clement, B.M. Peyton, T.R. Ginn, et.al. Modeling bacterial transport and accumulation process in saturated media: a review [J]. Advances in Nuclear Science and Technology (1999). Vol26, 59-78.

DOI: 10.1007/0-306-47088-8_3

[7] Manchao He, Bin Liu, Leihua Yaoet.al. Research on hydraulic conductivity in the process of rejection of underground hot water[J]. JOURNAL OF JILIN UNIVERSITY (EARTH SCIENCE EDITION) (2002). Vol32, 374-377.

[8] Bruce E. Rittmann. The significance of biofilm in porous media [J] Water Resources Research (1993). Vol. 29, 2195-2202

DOI: 10.1029/93wr00611

[9] Stewart W. Taylor, Peter R. Jaffe. Substrate and Biomass transport in a Porous Medium [J]. Water Resources Research (1990). Vol. 26,2181-2194

DOI: 10.1029/wr026i009p02181

[10] Makoto KIMURA, Zhong-Jun JIA. Ecology of viruses in soils: Past, present and future perspectives [J]. Soil Science and Plant Nutrition (2008) 54, 1-32

DOI: 10.1111/j.1747-0765.2007.00197.x

[11] Kai Zheng, Hongwei Fang, Lixu Wang. Bacterial growth in a groundwater source heat pump system[J]. JTsinghua

[12] C. Moyne, S. Didierjean, H.P.A. Souto, et al. Thermal dispersion in porous media: one-equation model [J]. International Journal of heat and mass transfer (2000).Vol.43, 3853-3867.

DOI: 10.1016/s0017-9310(00)00021-1

[13] S. Chevalier, O. Banton. Modeling of heat transfer with the random walk method. Part 1. Application to thermal energy storage in porous aquifers [J]. Journal of hydrology (1999). Vol.222,129-139

DOI: 10.1016/s0022-1694(99)00108-0

[14] Juntang Yu, Xiaoxuan Tang, Xingyan Wu et.al. New edition of biotechnology[M]. Beijing: Chemical Industry Press.

[15] Yuran Luo, Shuqin Yu, Zude Zhang et.al. Talk about activation energy [J]. College Chemistry [2010]. Vol25, 35-42.
