The Study of the Design Parameter of Lead Rubber Bearing

Abstract:

The Lead-Rubber-Bearing is a type of isolation device in entirety. Its design parameter is complicated. when it is used in bridges, it always need plenty of time to design. It is not beneficial to its application and dissemination. The design formula now available are lack of relevance，can not provide a clear and distinct computation measure. This paper explains in a systematic way the formula and reasonable value range of the design parameter. These parameters include the diameter and height of lead pin, effective design deflection, the equivalent linear model, shear strain of rubber bearing shear stress of the lead，initial rigidity and second rigidity and so on. At last this paper induces computing method of equivalent rigidity and equivalent damping constant and gives some examples。This paper gives scientific basis for the concrete design and makes the bearing standard and serial to lay a foundation for its application.

• Periodical: Applied Mechanics and Materials (Volumes 184-185)
• Pages: 591-594
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.184-185.591
• Online since: June 2012
• Authors: Jie Wang, Jian Xin Liu
• Keywords: Computing Method, Design Parameter, Equivalent Linear Model, Lead Rubber Bearing

References

[1] Jun-sheng Zhuang, Bridge Bearings, first ed., China Railway Press, BeiJing, (2000).

[2] JIan-xin Liu, Zhao-tong Hu, Design method Study on damping device of highway bridge, the Science and Technology Research Report, (2000).

[3] Li-chu Fan, Zhi-qiang Wang. Bridge Seismic Isolation Design, Communications Press, Beijing, (2000).

[4] Ministry of Transportation of the People's Republic of China, Compilation of special equipment and materials standards in Road and bridge, Communications Press, Beijing, (1999).
