Investigation of the Temperature Distribution in the Lithium-Ion Battery for Pure Electric Vehicles

Abstract:

Lithium-ion batteries have more excellent performance than other types of batteries, thus it is widely used in electric vehicles. Using batteries as the main power supplier does inevitably generate a lot of heat which not only deteriorates the batteries, but endangers the safety of the vehicle. In this paper, the temperature distribution of the batteries in the pure electric vehicles was investigated to minimize the heat generated in the batteries. The finite element formulations of the 3-D heat conduction equation of the battery were established for both steady and transient states. Then the finite element simulations were developed to investigate and optimize the temperature distribution of the battery and the battery pack. A parametric study was completed such that the heat generated in the battery pack can be minimized.

• Periodical: Applied Mechanics and Materials (Volume 187)
• Pages: 324-328
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.187.324
• Online since: June 2012
• Authors: Liang Zheng, Bin Wu, Guo Qing Xu
• Keywords: Finite Element Method (FEM), Lithium-Ion Battery, Pure Electric Vehicle, Thermal Analysis

References

[1] M. Einhorn, , W. Roessler; and J. Fleig: Improved performance of serially connected Li-ion batteries with active cell balancing in electric vehicles. IEEE Transactions on Vehicular Technology, Vol. 60, No. 6, pp.2448-2457, July (2011).

DOI: 10.1109/tvt.2011.2153886

[2] T. M. Bandhauer, S. Garimella, and T. F. Fuller: A critical review of thermal issues in lithium-ion batteries. Journal of the Electrochemical Society, Vol. 158, No. 3, p R1-R25, (2011).

DOI: 10.1149/1.3515880

[3] C. P. Guerrero, J. -S. Li, S. Biller, and G. -X. Xiao: Hybrid/electric vehicle battery manufacturing: The state-of-the-art, 2010 IEEE International Conference on Automation Science and Engineering, pp.281-286, (2010).

DOI: 10.1109/coase.2010.5584739

[4] J. P. Holman: Heat Transfer, p.4, ninth edition, McGraw-Hill (2002).

[5] R. D. Cook, D. S. Malkus, M. E. Plesha and R. J. Witt: Concepts and Applications of Finite Element Analysis, pp.464-466, fourth edition, John Wiley (2001).
