Powerful Gear Shifting Control for Hybrid Electric Bus with Automated Manual Transmission

Abstract:

Traditionally a gear shift with clutch and synchronizer control makes the synchronisation phase unnecessarily long torque gap time. Based on the benefit of a single shaft parallel hybrid electric bus (PHEV), fast gear shifting and reducing the shafts speed oscillation can be realized by controlling the electric machine with Model Predictive Control (MPC ) method instead of sliding the clutch and synchronizer to a torque-free state in the transmission. Detailed mathematical models of different driveline states are presented and to improve driving comfort. Theoretical and simulation analysis results are compared with experimental ones from the road experiment in equal conditions in order to prove the validity of the gear shifting control strategy.

• Periodical: Applied Mechanics and Materials (Volumes 195-196)
• Pages: 1023-1029
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.195-196.1023
• Online since: August 2012
• Authors: Yong Dan Chen, Jun Qiang Xi, Chun Guang Xu
• Keywords: Automated Manual Transmission (AMT), Gear Shifting, Hybrid Electric Bus, MPC

References

[1] Kulkarni M, Shim T, Zhang Y. Shift dynamics and control of dual-clutch transmissions[J]. Mechanism and Machine Theory. 2007, 42(2): 168-182.

DOI: 10.1016/j.mechmachtheory.2006.03.002

[2] Koprubasi K, Westervelt E, Rizzoni G, et al. Experimental validation of a model for control of drivability in a hybrid-electric vehicle: ASME Int. Mechanical Engineering Cong. [Z]. Seattle: (2007).

DOI: 10.1115/imece2007-41849

[3] Fischer R, Berger R. Automation of mannual transmission: 6th International Luk Symposium[Z]. 199895-121.

[4] Nordgard K, Hoonorst H. Development in automated clutch management system: SAE 950896[Z]. (1995).

[5] Galvagno E, Velardocchia M, Vigliani A. A model for a flywheel automatic assisted manual transmission[J]. Mechanism and Machine Theory. 2009, 44(6): 1294-1305.

DOI: 10.1016/j.mechmachtheory.2008.07.002

[6] Hyeoun-Dong, L., et al., Advanced gear-shifting and clutching strategy for a parallel-hybrid vehicle. Industry Applications Magazine, IEEE, 2000. 6(6): pp.26-32.

DOI: 10.1109/2943.877837

[7] Baraszu, R.C. and S.R. Cikanek. Torque fill-in for an automated shift manual transmission in a parallel hybrid electric vehicle. in American Control Conference, 2002. Proceedings of the 2002. (2002).

DOI: 10.1109/acc.2002.1023222

[8] Poursamad, A. and M. Montazeri, Design of genetic-fuzzy control strategy for parallel hybrid electric vehicles. Control Engineering Practice, 2008. 16(7): pp.861-873.

DOI: 10.1016/j.conengprac.2007.10.003

[9] Mashadi, B. and S.A.M. Emadi, Dual-Mode Power-Split Transmission for Hybrid Electric Vehicles. Vehicular Technology, IEEE Transactions on, 2010. 59(7): pp.3223-3232.

DOI: 10.1109/tvt.2010.2049870

[10] Kiencke, U. and L. Nielsen, Automotive Control Systems: For Engine, Driveline, and Vehicle. 2000, Berlin: Springer.
