The Study on the STEP-NC Program Generation for Milling Operations

Abstract:

STEP-NC is a new data model for data exchange between CAD / CAM and CNC, which provides rich information for CNC machine tools and tells CNC “what to do”rather than “how to do”, overcomes many shortcomings of the traditional G&M codes and has become a hot research issue now. How to efficiently and cost-effectively generate the STEP-NC program is a very crucial problem. Although some domestic scholars have done some research about STEP-NC program generation, most of them do second development base on ST-Developer software. The paper developed a STEP-NC program generation module by using the VC++6.0 and CAD / CAM software. The module can read AP203 file generated by CAD system, identify manufacturing features according to its geometry information and conduct process planning to generate STEP-NC file according to ISO14649 standard. This module has been proved effectively by an instance.

• Periodical: Applied Mechanics and Materials (Volume 197)
• Pages: 362-366
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.197.362
• Online since: September 2012
• Authors: Lin Yang, Rui Nan Wu, Jin Yuan Wang
• Keywords: AP203, Feature Extraction, STEP-NC, VC++
