A Study on a New Method for Measuring Positioning Accuracy of Multi-Station Turntable

Abstract:

Multi-station turntable, widely used in industrial automation field, has become an indispensable device in the automation assembly line. The positioning accuracy of traditional mechanical turntable is largely affected by the machining accuracy of Geneva wheel, Ratchet and Cam. The positioning accuracy level has a crucial influence on processing and assembly accuracy, and production efficiency. This paper presents a measuring method to measure positioning accuracy by eddy current sensor. To achieve the positioning accuracy the writer measures the distance between the probe and the measuring block in the circumferential tangent direction. When the turntable turns to a station, the sensor probe is manually adjusted to align it with the measuring block. In this way, the positioning accuracy can be measured conveniently and directly.

• Periodical: Applied Mechanics and Materials (Volumes 198-199)
• Pages: 1286-1289
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.198-199.1286
• Online since: September 2012
• Authors: Liang Han, Li Yang Zhang, Wei Zhong Wu, Cheng Hao
• Keywords: Eddy Current Sensor, Measuring Method, Multi-Station Turntable, Positioning Accuracy

References

[1] Yuan Zhongfan, Mechatronics Technology [M]. Beijing: Electronic Industry Press, (2006).

[2] Zhang Jian-min. Mechanical-Electrical Integration System Design[M]. Beijing: Higher Education Press, 2007: 90-124.

[3] Xu Xianghe, Elctronic and Precision Mechanical Design[M]. Nanjing: Publishing House of Southeast University, 2000 10: 75-78.

[4] Zheng Wenwei, Wu Kejian, Mechanical Principal [M]. Beijing: Higher Education Press, 1997 7: 57-60.

[5] Wu Kejian, Yu Xiaohong, Qian Ruiming. Mechanical Design[M]. Beijing: Higher Education Press, 2003 3: 86-95.

[6] Ye Hui. Research on high smooth and low speed turn-table angular measurement system. Harbin Institute of Technology (2006).

[7] Bai Ming-fang, Yang Rui-feng. High Precision Angle and Velocity Measuring System. Taiyuan: North University of China; Mechanical Management and Development, (2010) 4: 51-51, 54.

[8] Tan Zu-Gen, Cheng Shou-Chuan. The Analysis and Parameter Selection on the Fundamentals of Eddy Current Transduces [J]. Chinese Journal of Scientific Instrument (1980).

[9] Liu Jiaxin, Yang Li Jian, Chen Peng. Selection of eddy current displacement sensor probe parameter[J]. Success (education), (2007).

[10] Jiang Yin-xiao, Tang Ji-qiang. Application Analysis of Dynamic Characteristic for Eddy Current Displacement Sensor. Aviation Precision Manufacturing Technology (2011).
