Innovative Design Based on Prototypes of the Main Mechanism of Table Lamp

Abstract:

On the basis of analyzing the topological structure of an original mechanism, it leads to the generalized kinematic chain meeting the same topological structure characteristics of the original mechanism in accordance with the generalized principle of mechanism, number synthesis of kinematic chain and compound hings. Allocation of ground links and performing links in the kinematic chain can get all feasible specialized kinematic chains while considering practical design constraints. In the final step, concrete schematic diagram of mechanism being restored from specialized kinematic chains leads to a series of new mechanism different from the original one. Designers ascertain appropriate new mechanism after selection and analysis.

• Periodical: Applied Mechanics and Materials (Volumes 198-199)
• Pages: 189-192
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.198-199.189
• Online since: September 2012
• Authors: Wan Chun Zhou, Jian Jun Lu
• Keywords: Generalized Kinematic Chains, Innovative Design, Mechanism, Topological Structure

References

[1] Zhou Wan-chun, Zhou T, and Wang D. The Innovative Design of Folding Umbrellalike Mechanism[J]. Trans Tech Publications Ltd, Laubisrutistr. 24, Stafa-Zuerich, CH-8712, Switzerland，September, 2009，pp.109-112.

[2] Zhou Wan-chun & Zhang Yong-yu. Robot Humanoid Hand Index Finger Type of Creative Design Agency[C]/ 2010 The 2nd International Conference on Computer and Automation. Chongqing: IEEE Computer Society, 2010: 250-252.

DOI: 10.1109/iccae.2010.5451711

[3] Yan Hong-sen, the writer. Yao Yan'an, Wang Yu-xin, Guo Ke-qian, translators. The Creative Design of Mechanical Devices[M]. Beijing: China Machine Press, 2002. 7.

[4] Zhang Chun-lin. The Mechanical Creative Design[M]. Beijing: China Machine Press, (1999).

[5] Wu Min, Ding Wei, Cao Weihua. Sintering ingredients optimize based on hybrid particle swarm algorithm [J]. Information and control, 2008, 37(2): 242–246.

[6] Xu Wei. Applications of ant colony algorithm in sinter ore blender ingredients [J]. Metallurgical automation, 2007, (6): 12–15.

[7] Shi Y, Eberhart R C . Empirical Study of Particle Swarm Optimization. In: Proceedings of the IEEE Congress on Evolutionary Computation. Piscataway, NJ, IEEE Service Centerm, 1999: 1945-(1950).

[8] Hossein M N , Nima T. New robust efficient ant colony algorithms: Using new interpretation of local updating process [J]. Expert Systems with Applications，2009，36: 252-260.

DOI: 10.1016/j.eswa.2007.09.048

[9] Soeha K，Dorigo M. Ant colony optimization for continuous domains [J]. European Journal of Operational Research，2008，185: 1155-1173.

DOI: 10.1016/j.ejor.2006.06.046
