Mechanism Research on Multi-Wedge Synchrostep Rolling Asymmetric Shaft-Parts by Cross-Wedge Rolling

Abstract:

Because most of the asymmetric shaft-parts have relatively large size in the axial direction, single-wedge cross-wedge rolling (CWR) exposes many imperfections, such as the huge roller, higher cost etc. The paper adopted finite element method (FEM) to simulate multi-wedge synchrostep CWR (MS-CWR) based on the typical asymmetric shaft-part, and gained its distribution and characteristics of stress and strain. In the knifing stage, the deformation of work piece only emerges on the local region, but in the stretching stage, most of regions are observed the deformation except two ends of the billet and the transition position between inner and outer wedge of multi-wedges. The results offer theoretical basis for promoting and applying MS-CWR technology on asymmetric shaft-parts.

• Periodical: Applied Mechanics and Materials (Volumes 201-202)
• Pages: 1061-1065
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.201-202.1061
• Online since: October 2012
• Authors: Le Ping Chen, Xue Dao Shu, Wen Fei Peng, Bao Shou Sun
• Keywords: Asymmetric Shaft-Parts, Cross Wedge Rolling (CWR), Multi-Wedge Synchrostep

References

[1] Z. Shen: Study of forming Process for big size Cross Wedge Rolling workpiece(MS., China Academy of Machinery Science and Technology, China 2006),pp.14-15. (In Chinese)

[2] J.G. Li: The study of regularities of the distortion of the workpiece by cross wedge rolling(MS., University of Science and Technology Beijing,China 2007),pp.5-6. (In Chinese)

[3] D.Zh. Huang and J.J. Zhou: Automobile of Science and Technology, Vol. 6 (1998) No.4, pp.22-29. (In Chinese)

[4] Forging Technology of Mechanical and Electrical Technology: Forging manual(Mechanical Industry Press, China 1987) (In Chinese)

[5] W.G. Zhang: Study of three dimensional force by cross wedge rolling(MS., University of Science and Technology Beijing,China 1985), pp.3-5. (In Chinese)

[6] Z.H.Hu, K.S. Zhang, B.Y. Wang, X.D. Shu and C.P. Yang: Forming Technology by Cross-wedge Rolling and Simulation (Metallurgy Industry Press,China 2004). (In Chinese)

[7] Z.H.Hu, K.S. Zhang and B.Y. Wang: The Theory and Application of Cross Wedge Rolling (Metallurgy Industry Press,China 1996). (In Chinese)

[8] X.D. Shu, C.M. Li and Z.H. Hu: Journal of Materials Processing Technology, Vol.187 (2007), pp.752-756.

[9] W.F. Peng, K.S. Zhang, Z. Jia and Z.H. Hu:Journal of Plasticity Engineering.Vol.17 (2010) No.2,pp.79-84. (In Chinese)

[10] X.D. Shu: Theory and Applications of Cross Wedge Rolling Multi-wedge Synchronization Rolling (Science Press, China 2011). (In Chinese)

[11] J. Zhao: Study on the Key Techonology of Multi-wedge Cross Rolling Forming a Long Shaft Part(Ph.D., University of Science and Technology Beijing,China 2007), pp.11-15. (In Chinese)
