Poincare Sphere Method in the Analysis of Fiber Polarization Mode Dispersion

Abstract:

With the continuous improvement of the optical fiber communication rate, polarization mode dispersion (PMD: Polarization mode dispersion) is gradually depth. PMD will cause the light pulse signal wide during transmission, and in the signal transmission process continuous accumulation, damage to the transmission performance of the system, limit the system's transmission rate and transmission distance, PMD began to be the main obstacle which constrained optical fiber communication system upgrade and further development. PMD is a random value and difficult to calculate and test in the actual optical fiber communication systems. Poincare method is intuitive, easy to understand, easy measurement to study the characteristics of the PMD, and avoid a lot of tedious calculations. In the paper, analysis the single-mode fiber and its PMD, and the polarization state transmission process of polarization maintaining fiber and its nonlinear effects using the Poincare method, and simulate PMD characteristics by using Matlab software. Based on these, introduce the measurement principle of an improved Poincare method. Analysis showed that the Poincare sphere is a unique method in the analysis of fiber-optic polarization state transmission. Poincare method for the study of polarization mode dispersion has become an important direction of today's communications field.

• Periodical: Applied Mechanics and Materials (Volume 203)
• Pages: 504-508
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.203.504
• Online since: October 2012
• Authors: Feng Wang, Li Zhen Feng, Kuan Wang
• Keywords: Differential Group Delay, Nonlinear Birefringence, Poincare, Polarization Mode Dispersion, Polarization State, Principal State of Polarization

References

[1] Zhou Guangtao, Zhang Xiaoguang etal. The First-order PMD Adaptive Compensation Experiment in 10 Gb/s Optical Communication System [J]. Acta Photonica Sinica. Vol. 4(2004), p.448.

[2] Zhou Yingwu, Guo Lingwei etal. Analysis of Statistical Characteristics of the First and Second Order Polarization Mode Dispersion of PMD Emulator [J]. Acta Photonica Sinica. Vol. 3(2004), pp.333-337.

[3] Xie Yuehui, Zhangxia, etal. Study of the Arithmetic of Poincare Sphere Method to Measure Polarization Mode Dispersion [J]. Chinese Journal of Lasers. Vol. 1(2003), p.49.

[4] Zhao Jingxi, Gui Lv. Fast Measurement of Polarization Mode Dispersion Using Improved Poincaré Sphere Method [J]. Journal of Optoelectronics. laser. Vol. 3(2004), pp.318-321.

[5] Zhang Xia, Zhang Xiaoguang. Investigation on the Statistical Characteristics of Polarization in High Speed Optical Communication Systems [J]. Modern cable transmission. Vol. 9(2002), p.40.

[6] Wang Junli, Fang Qiang, etal. Comparison among Polarization Mode Dispersion MeasurementTechniques in Single-mode Optical Fibers [J]. Semiconductor Optoelectronics. Vol. 5(2004), p.332.
