Bearing Performances of a Strengthened Chinese Ancient Beam by Simulation

Abstract:

To protect Chinese ancient wooden buildings, by simulation means a decayed wooden beam of an ancient building in the Forbidden City was taken as example to study its bearing performances after strengthened by steel bands and bolts.The ancient wooden beam was found to decay on its forepart.The decayed part of beam was considered to be replaced by new wooden part,which connected with old part of beam by bolts and steel bands.Finite element model of the strengthened beam was built considering swivel type of boundary conditions.By contact analysis of ANSYS program, distortion value,compression,tension as well as contact stresses of the strengthened beam under vertical loads were obtained, feasible strengthening suggestions were proposed.Results show that inner forces and distortion value of the strengthened beam are within permission scopes,thus the strengthening method is feasible.

• Periodical: Applied Mechanics and Materials (Volumes 204-208)
• Pages: 2903-2906
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.204-208.2903
• Online since: October 2012
• Authors: Qian Zhou*, Wei Ming Yan
• Keywords: Chinese Ancient Wooden Building, Contact Analysis, Decayed Beam, Simulation, Strengthening

References

[1] D.K. Liu: Techniques of Traditional Buildings and Gardens, Vol. 3 (2001), p.58.

[2] National Standards of the People's Republic of China: Technical Code for Maintenance and Strengthening of Ancient Timber Buildings (GB50165-92) (China Architecture & Building Press, PRC 1992).

[3] National Standards of the People's Republic of China: Code for Design of Timber Structures (GB50005- 2003) (China Planning Press, PRC 2003).

[4] National Standards of the People's Republic of China: Code for Design of Steel Structures (GB50017-2003) (China Planning Press, PRC 2003).
