Fatigue Stress Analysis of Diaphragm Cap Hole in Orthotropic Steel Bridge Decks

Abstract:

Influence of diaphragm parameter on stress amplitude and fatigue damage of diaphragm details were investigated based on Tai Zhou Yangtze River Bridge. FEM of steel bridge deck and diaphragm detail were established. Boundary conditions of the diaphragm details FEM were interpolated by sub-model method, and the accurate local stresses of diaphragm details correspond to different lateral distribution of wheels were calculated. Results show the stress amplitude of diaphragm details reach maximum when wheel off-center position is 150mm, and it decreases with the increase of wheel off-center position greatly. The stress amplitude of diaphragm details increase with the increase of the distance of diaphragms, and increasing diaphragm’s thickness can improve fatigue stress of steel bridge deck.

• Periodical: Applied Mechanics and Materials (Volumes 204-208)
• Pages: 3265-3269
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.204-208.3265
• Online since: October 2012
• Authors: Mu Ye Yang, Rong Liu, Bo Hai Ji, Han Jiang Xu, Ce Chen, Duan Duan Zhao
• Keywords: Diaphragm Cap Hole, Fatigue Stress, Orthotropic Steel Bridge Deck, Vehicle Load

References

[1] Tong Lewei, Shen Zuyan. Fatigue Assessment of Orthotropic Steel Bridge Decks [J]. China Civil Engineering Journal, 2000, 33(3): 16-21.

[2] Wang Chunsheng, Feng Yacheng. Review of Fatigue Research for Orthotropics Steel Bridge Decks[J]. Steel Construction, 2009, 9(24): 9-13.

[3] Committee of Steel Construction Society of Civil Engineers. Committee Report of Research on Thick Plate Welded Joints [R].Japan: 2007.

[4] J.S. Leendertz. Fatigue Behaviour of Closed Stiffener to Crossbeam Connections in Orthotropic Steel Bridge Decks[R]. Technische Universiteit Delft, 2008.

[5] Eurocode3, Design of Steel Structures-Part2: Steel Bridges[S]. PREN1993-1-9, 2002.

[6] Tang Liang, Huang Liji, Liu Gao. FEA of Stress along Cope Hole Edge of Crossbeam in Orthotropic Steel Deck[J]. Journal of Highway and Transportation Research and Development, 2011, 28(6): 83-90.

[7] American Association of State Highway and Transportation Officials (AASHTO). AASHTO LRFD Bridge design specifications, 3rd Ed., Washington, D.C., 2004.

[8] Liu Baiming, Wang Bangmei. Cable-stayed Bridge Manual [M].Beijing: China Communications Press, 2006.

[9] Zhou Mengbo. Suspension Bridge Manual [M]. Beijing: China Communications Press, 2003.

[10] Samol Ya, Kentaro Yamada. Fatigue Durability Evaluation of Trough to Deck Plate Welded Joint of Orthotropic Steel Deck[J]. Structural Eng. / Earthquake Eng., JSCE, 2008, 25, 33-46.

DOI: 10.2208/jsceseee.25.33s

[11] British Standard. Steel, concrete and composite bridges- Part10: Code of practice for fatigue[S]. 3rd Ed, London. 2001.

[12] Zhang lei，Basic Study of fatigue design load for steel highway bridges[J]. Shanghai: Tongji University, 2009.

[13] Eurocode3, Design of Steel Structures-Part1.9: Fatigue Strength of Steel Structure[S]. PREN1993-1-9, 2002.
