Research of Virtual Cutting Based on Hap Tic Feedback

Abstract:

As product design has entered the stage of green design, virtual design becomes increasingly important, and cutting research is the core of it. This paper established a basic virtual cutting system and the grid models of virtual objects based on PHANTOM Omni hap tic feedback device and its system development toolkit and built up oriented bounding box and operated bounding box collision detection. On the base of these, the paper also presented a new method of cutting force condition judgment of cutting tool, and gave the cutting path planning and grid model reconstruction on the basis of virtual cutting methods of triangular grid unit model. At last, the paper researched the virtual cutting of grid model using computer programming language, providing design methods for product design. The relative methods may advance the effect of product design drastically.

• Periodical: Applied Mechanics and Materials (Volume 214)
• Pages: 944-948
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.214.944
• Online since: November 2012
• Authors: Yan Zhou, Deng Ming Hu
• Keywords: Collision Detection, Cutting Force, Hap Tic Feedback, Triangular Grid Unit, Virtual Cutting

References

[1] S. Gottschalk, M.C. Lin and D. Manocha, OBBTree: A Hirearchical Strcuture for Rapid Interference Detection, in: Proceeding SIGGRAPH '96 Proceedings of the 23rd annual conference on Computer graphics and interactive techniques, pp.171-180 (1996).

DOI: 10.1145/237170.237244

[2] M. Lahanas, T. Kemmerer and N. Milickovic, Optimized bounding boxes for three-dimensional treatment planning in brachytherapy, Medical Physics, Vol. 27 (2000).

DOI: 10.1118/1.1312808

[3] S. Ding, M.A. Mannan and A.N. Poo, Oriented bounding box and octree based global interference detection in 5-axis machining of free-form surfaces, Computer-Aided Design, Vol. 83(2004), pp.1281-1294.

DOI: 10.1016/s0010-4485(03)00109-x

[4] [A. Gregory, M.C. Ling and R. Taylor, A framework for fast and accurate collision detection for haptic interaction, in: Proceeding SIGGRAPH '05 ACM SIGGRAPH 2005 Courses, 34(2005).

DOI: 10.1145/1198555.1198604
