Simulation Analysis for Supercavitation Projectiles Penetrating into Metal Targets

Abstract:

The process of the supercavitation projectile penetrating into metal targets was simulated by using the dynamic analysis software ANSYS/LS-DYNA, and the deformation、breakage and forces on the body in different initial velocities and the penetration depth were discussed. Analysis results show that there are two peaks of resistance and the velocities is variety almost in linear attenuation when the cone part of the projectile is moving through contacted with the target plate, which provides references for the structure and parameters design of the supercavitation projectile.

• Periodical: Applied Mechanics and Materials (Volumes 217-219)
• Pages: 1449-1454
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.217-219.1449
• Online since: November 2012
• Authors: Wei Cao, Tie Zhi Sun, Cong Wang, Xin Hua Zhao
• Keywords: High-Speed Projectile, Numerical Simulation, Penetration, Supercavitation

References

[1] Jianhua Luo. The Testing Technology and Numerical Simulation on Kinetic Energy Projectile Penetrating into Concrete Target. TaiYuan: North University of China. 2009. (in Chinese)

[2] Y.N. Savchenko, in: 4th International Symposium on Cavitation, edited by E.B. Christopher//California Institute of Technology Pasadena, California, lecture 3 (2001)

[3] É.L. AMROMINL, V.A. BUSHKOVSKIIL, D.I. DIANOVL: Fluid Dynamics, Vol. 18(5)(2008), pp.816-820.

[4] Information on http: //www.ctechdefense.com/ projects.html

[5] Daqiao Jin, Cong Wang, Feng Yu: Aerodynamic Missile Journal, Vol. 40(7)(2010), pp.19-23. (in Chinese)

[6] Livermore software technology corporation. LS-DYNA Keyword User's Manual. California: Livermore software technology corporation, 2001, Vol 2: 68-71.

[7] Zhigang Wei. Study on deformation and failure behavior of WHA and penetration mechanism of WHA projectiles. Hefei: University of Science and Technology of China. 2001. (in Chinese)
