Numerical Simulation for Technological Parameters of Vibratory Stress Relief in Large Welding Structures

Abstract:

In order to obtain the natural frequency, vibration mode and the curves of amplitude-frequency under two supporting ways, dynamic analysis was carried out on the large plane steel gate structures of a hydraulic projects. According to the Chinese machinery industry standard of vibration stress relief, technological parameters and effective range of vibratory stress relief were determined under two supporting ways. Some valuable references of determining technological parameters of vibratory stress relief for the plane steel gate structures and other momentous welding structures were provided through the research results and the conclusions.

• Periodical: Applied Mechanics and Materials (Volumes 217-219)
• Pages: 2046-2050
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.217-219.2046
• Online since: November 2012
• Authors: Jian Ke Fu, Xiao Hui Huang, Liang Xu
• Keywords: Dynamic Analysis, Finite Element, Technological Parameter, Vibratory Stress Relief

References

[1] Delin Rao, Zhengqiang Zhu, Jingguo Ge, Ligong Chen, Chunzhen Ni. Vibration and shock. Vol 2,2005 (In Chinese)

[2] Defen Zhang, Chengjiang Yin, Xiaowen Chen, Fating Wan, Tianmin Song. Journal of Fushun Petroleum Institute. Vol. 20,2000 (In Chinese)

[3] Jianke Fu, Xiaoping Lei, Wanli Fan. Mechanical design and manufacturing. Vol. 12,2009 (In Chinese)

[4] Baomin Yu, Zhanli Huang. Machinery Design & Manufacture. Vol. 9,2005 (In Chinese)

[5] JB/T10375-2002. Vibratory stress relief technology parameters selection and technical requirements for welded Components.
