A Comparison of Characteristics of Improved Total Contact Insoles

Abstract:

The purpose of this study is to investigate the effects of two kinds of total contact insoles (TCI). Traditional TCI reflects the shape of foot, while deformed total contact insole(DTCI) was established basing on the shape of footprints on clay prototypes. A female experimenter was asked to exert different loadings on clay prototypes to make footprints. Shapes of the footprints have been recorded by a reverse engineering method. Force distribution results in given preconditions were reflected and recorded for quantified comparison. shapes of two total contact insoles were rebuilt under different loadings. Having deformation of different magnitude over each area as a reference, effect and possibility of further improvement have been explored. Our findings showed that insoles based on larger deformation can be utilized to redistribute peak pressure effectively under normal loading. The results indicates that DTCI in this study can be used as a more important tool in adjusting functions or comfort ratings of shoes.

• Periodical: Applied Mechanics and Materials (Volumes 226-228)
• Pages: 2207-2210
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.226-228.2207
• Online since: November 2012
• Authors: Qi Wang, Qing Ming Wang
• Keywords: Deformation, Foot, Pressure, Soft Tissue

References

[1] L.A. Lavery, D.G. Armstrong, R.P. Wunderlich, J. Tredwell, A.J. Boulton, in: Predictive Value of Foot Pressure Assessment as Part of a Population-based Diabetes Disease Management Program, volume 26 of Diabetes Care,1069-1073(2003).

DOI: 10.2337/diacare.26.4.1069

[2] T.G. McPoil, M.W. Cornwall, W. Yamada, in: A Comparison of Two in Shoe Planter Pressure Measurement Systems, volume 26 of Lower Extremity 95-103(1995).

[3] J.H. Ahroni, E.J. Boyko, R. Forsberg, in: Reliability of F-scan In-shoe Measurements of Plantar Pressure, volume 19 of Foot Ankle, 668-673(1998).

DOI: 10.1177/107110079801901004

[4] W.P. Chen, C.W. Ju and F.T. Tang, in: Effects of Total Contact Insoles on the Plantar Stress Redistribution: A Finite Element Analysis, volume 18 of Clin Biomech, 17−24(2003).

DOI: 10.1016/s0268-0033(03)00080-9

[5] A. Raspovic, L. Newcombe, J. Lloyd, E. Dalton, in: Effect of Customized Insoles on Vertical Plantar Pressures in Sites of Previous Neuropathic Ulceration in the Diabetic Foot, volume 10 of Foot (2000).

DOI: 10.1054/foot.2000.0604

[6] T.Y. Shiang, in: The Nonlinear Finite Element Analysis and Plantar Pressure Measurement for Various Shoe Soles in Heel Region, volume 21 of Proc Natl Sci Counc Repub China B 168-74(1997).

[7] M.Brown, S.Rudicel, A.Esquenazi, in: Measurement of Dynamic Pressures at the Shoe–foot Interface During Normal Walking with Various Foot Orthoses Using the FSCAN System, volume 17 of Foot Ankle Int, 152–156(1996).

DOI: 10.1177/107110079601700306

[8] S.Jacob, M.K. Patil, in: Stress Analysis in Three-dimensional Foot Models of Normal and Diabetic Neuropathy, volume 9 of Front Med Biol Eng,211-27(1999).

[9] A.H. Hansen, M.R. Meier, P.H. Sessoms, D.S. Childress, in: The Effects of Prosthetic Foot Roll-over Shape Arc Length on the Gait of Trans-tibial Prosthesis Users, volume 3 of Prosthetics and Orthotics International,286–299(2006).

DOI: 10.1080/03093640600816982

[10] A.H. Hansen, D.S. Childress, in: Effects of Shoe Heel Height on Biologic Rollover Characteristics During Walking, volume 4 of Journal of Rehabilitation Research and Development, 547–554(2004).

DOI: 10.1682/jrrd.2003.06.0098
