Analysis on Oil Whip of Steam Turbine

Abstract:

Oil whip, which is one of the typical types of steam turbine failure, may lead to large amplitude vibration of the rotor and even to catastrophic accident. In order to prevent and on-line eliminate the oil whip, researches on vibration of steam turbine caused by the oil whip and its characteristics have been elaborated from two respects of theory and experiment. The causes and the formation mechanism of the oil whip have been analyzed, and in certain conditions, a series of experiments for the oil whip on the rotor experiment rig have been made. Illustrating and summarizing the results of these experiments by change the rotor speed and the lubricant quantity. These researches on the oil whip could provide some theoretical bases for the practical work. Along with the expounded prevention measures of oil whip, some ideas on oil whip online elimination are put forward.

You might also be interested in these eBooks

Vibration, Structural Engineering and Measurement II

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 226-228)

Pages:

56-59

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.226-228.56

Citation:

Cite this paper

Online since:

November 2012

Authors:

Xiao Lu Peng, Jin Qian, Bin Zhang, Rui Xiong Peng

Keywords:

Elimination Measure, Experiment, Oil Whip, Steam Turbine

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] B.L. Newkirk: "Shaft Whipping", G.E. Review, (1924), p.169.

Google Scholar

[2] T. Yamamoto: "On Critical Speeds of a Shaft Supported by a Ball Bearing", Trans. ASME, Vol. 26 (1959) No.2, p.199.

Google Scholar

[3] K. Shiraki: "Troubleshooting of Vibration Problems in the Field", Journal of JSME, Vol.75 (1972) No.639, p.507.

Google Scholar

[4] B.L. Newkirk and H.D. Taylor: "Shaft Whipping Due to Oil Action in Journal Bearings", General Electric Review,(1925),p.559.

Google Scholar

[5] J.W. Lund: "Spring and Damping Coefficients for the Tilting Pad Journal Bearing", ASLE Trans, Vol.7, (1964), p.342.

Google Scholar

[6] F.K. Orcutt: "The Steady-State and Dynamic Characteristics of the Tilting-Pad Journal Bearing in Laminar and Turbulent Flow Regimes", Trans.ASME, Vol.89 (1967), p.392.

DOI: 10.1115/1.3617003

Google Scholar

[7] S. Iida: "A Study on the Vibration Characteristics of Tilting Pad Journal Bearings", Trans. JSME, Vol.40 (1974) No.331, p.875.

Google Scholar

[8] H. Hashimoto, S. Wada and T. Marukawa: "Performance Characteristics of Large Scale Tilting-Pad Journal Bearings", Bulletin, Japan Society of Mechanical Engineers,(1985), p.1761.

DOI: 10.1299/jsme1958.28.1761

Google Scholar
