Based on the PS/T Method Control Design of Flexible Systems

Abstract:

The lightly damped resonant poles of flexible system increased norm of coprime factor perturbation, which reduced robust of system after loop shaping design. This paper proposes approaches considering the performance of constraints, to select performance weight function through disturbance attenuation and to adjust the complementary sensitivity weight function through design index. The flexible satellite's attitude control demonstrates that the two approaches are able to rapidly select weight function under ensuring the system's robust and have the ability to depress disturbance.

• Periodical: Applied Mechanics and Materials (Volumes 236-237)
• Pages: 370-377
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.236-237.370
• Online since: November 2012
• Authors: Fan Wei Meng, Zhen He, Zu Yu Yu, Li Hua Wang
• Keywords: Bode Integral, Flexible Systems, Performance Index, PS/T Problem, Robustness

References

[1] McFarlane D, Glover K．A Loop shaping design procedure using H∞ synthesis [J]．IEEE Transactions on Automatic Control，1992， 37(6) ：759~769.

DOI: 10.1109/9.256330

[2] Glover K, McFarlane D． Robust Controller Design Using Normalized Coprime Factor Plant Descriptions [M]．Lecture Notes in Control and Information Sciences, Vol. 138．New York： Springer-Verlag, 1990.

DOI: 10.1007/bfb0043199

[3] He Zhen , Meng Fan-Wei , Liu Wei, et al. Robustness of H∞ Loop Shaping Design [J]. Acta Automatica Sinica, 2010, 36(6): 890 – 893.

DOI: 10.3724/sp.j.1004.2010.00890

[4] LANZON A, TSIOTRAS P. A combined application of H∞ loop shaping and μ-synthesis to control high-speed flywheels[J]. IEEE Control Systems Technology, 2005, 13(5): 766 – 777.

DOI: 10.1109/tcst.2005.847344

[5] HE Zhen, JIANG Xiaoming, MENG Fanwei, et al. μ-synthesis in H-infinity loop-shaping design [J]. Control Theory and Applications, 2012, 29 (3): 347 – 352.

[6] Wang Guang-xiong, HE Zhen. Control System Design[M]. Beijing: Tsinghua University Press, (2008).

[7] K. J. Åström, H. Panagopoulos and T. Hägglund, Design of PI controllers based on non–convex optimization. Automatica, 34(5), 1998: 585–601.

DOI: 10.1016/s0005-1098(98)00011-9

[8] G. Stein, Respect the unstable. IEEE Control Systems Magazine, 23(4), 2003: 12–25.

[9] Meng Fan-Wei, He Zhen, Wang Yi, et al. H∞ state feedback design of an electromagnetic suspension system [J]. Electric Machines and Control 2009, 13(2): 282-286(in Chinese).

[10] J. C. Doyle, K. Glover, P. P. Khargonekar, B. A. Francis. State-space solutions to standard H2 and H∞ control problems[J]. IEEE Transactions Automatic Control, 1989, 34(8): 831-847.

DOI: 10.1109/9.29425

[11] Franklin G F, Powell J D, Emami-Naeini A. Feedback Control of Dynamic Systems (Fourth Edition). Beijing: Pearson Education, (2003).
