Study on Fundamental Frequency of Runway Based on Winkler Model

Abstract:

The change mechanisms of fundamental frequency of runway under different conditions are discussed in this paper. A full scale cement concrete slab finite element model is built to analyze the relationship between foundation modulus and the fundamental frequency of runway. The results show that the coupling effect of runway plates can not be neglected. The minimum area affecting the fundamental frequency of runway is 45m in longitudinal and 15m in transversal according to the analysis of fundamental frequency of different size runway. The fundamental frequency of runway ranges from 7.5Hz to 23.6 Hz when the foundation modulus increases.

• Periodical: Applied Mechanics and Materials (Volume 238)
• Pages: 278-281
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.238.278
• Online since: November 2012
• Authors: Xian Min Zhang, Liang Liang, Zhang Wei
• Keywords: Finite Element, Fundamental Frequency, Pavement, Winkler Foundation

References

[1] Kantorovich L V, Krylov V I, Approximate Methods of Higher Analysis, Noordhoff Groningen, the Netherland, 1964.

[2] X. Zheng, S. Wang, Dynamic Response Analysis of Airport Pavement, Acta Aeronautica et Astronautica Sinica, 3 (1990) 35-38.

[3] Y. Zhong, F. Zhou, Y. Zhang, Vibration analysis of a thin plate on Winkler foundation with completely free boundary by Kantorovich method, Journal Of Vibration Shoct., 3 (2007) 53-57.

[4] C. Yang, L. Liu, Dynamic response analysis of cement concrete pavement under different vehicle speed, Journal of Hebei University of Technology, 3 (2010) 63-66.

[5] Z. Zhou, J. Ling, J. Yuan, 3D finite element analysis of the load transfer efficiency of joints of airport rigid pavement, China Civil Engineering Journal, 2 (2009) 22-25.

[6] J. Zhang, X. Zhang, A simple way of estimating load-carrying capacity of airport pavement, Journal of Northwestern Polytechnical University, 1 (2004) 19-22.
