System Identification Applications in Pavement Permittivity Back-Calculation

Abstract:

The Ground Penetrating Radar (GPR) has been widely used in the road quality control of construction, maintenance management and deterioration investigation for its rapid, nondestructive and high efficient advantages. Whereas, the pavement layer thickness accuracy measured by GPR is not satisfied under any conditions, and the coring calibration must be done. Based on System Identification (SI) theory, sensitivity analysis method and the singular value decomposition of matrix technology, an inverse method is presented to back-calculate pavement permittivity and analyze layer thickness used the GPR waveform reflected by pavement structure. The experiments show the algorithm is faster, more stable and more accurate in thickness calculation. When it is used in GPR data analysis, the traditional coring calibration will be reduced or avoided.

• Periodical: Applied Mechanics and Materials (Volume 238)
• Pages: 366-370
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.238.366
• Online since: November 2012
• Authors: Mei Li Meng, Ying Chun Cai, Bei Zhang
• Keywords: Bridge, Dam Slope Stability, Homogeneous Clay Dam, Seepage Flow

References

[1] Y.Cai, Inverse Analysis of Dielectric Properties for Layered Inhomogenous Media—Study on Applied Technology of Ground Penetrating Radar. Dalian University of Technology, 2008.

[2] Timo Saarenketo, Tom Scullion. Road evaluation with ground penetrating radar, Journal of Applied Geophysics, 43 (2000) 73-88.

DOI: 10.1016/s0926-9851(99)00052-x

[3] B. Zhang, System Identification Method for Backcalculating the Dielectric Property and Thickness of Pavement Structures—Study on Applied Technology of Ground Penetrating Radar, Chongqing University, 2003.

[4] Fernando Emmanuel, Liu Wenting, Dietrich Bruce, Computer program for network level determination of pavement layer thicknesses, Proceedings of SPIE -The International Society for Optical Engineering, 2000, V4084:194-199.

[5] Y. Cai, F. Wang, H. Kang, Research and application of backcalculation for pavement permittivity by Genetic Algorithm. Journal of Wuhan University of Technology (Transportation Science & Engineering), 34 (2010) 542-544.

[6] Amara Loulizi, Development of Ground Penetrating Radar Signal Modeling and Implementation for Transportation Infrastructure Assessment, U.S. the Virginia Polytechnic Institute and State University, 2001.

[7] X. Dong, W. Wang, Parameter inversion of stratified media based on time domain reflection data, Acta Electronica Sinica, 9 (1999) 59-62.

[8] M. Meng, Simulation of Ground Penetrating Radar Echo Waves in Pavement Layers, Zhengzhou University, 2002.

[9] X. Tao, Research on the Application of Road Radar Technology, Zhengzhou University, 2002.

[10] F. Wang, R. L. Lytton, System Identification Method for Backcalculating Pavement Layer Properties, TRB.1993, V1384,pp. l-7.
