Constitutive Relationship of 3A21 Aluminium Alloy Tube for Magnetic Pulse Forming

Abstract:

In this work, Split Hopkinson Pressure Bar (SHPB) was employed to test the material properties dynamic forming. The stress-strain curves and dynamic yield strengths under variable strain rates were obtained. Constitutive equation of 3A21 aluminium alloy was formulated by Johnson-Cook model and then, it was applied to simulate the forming behavior of 3A21 aluminum alloy tube under dynamic state by software Ansys/ls-dyna. The results show that, for magnetic pulse forming process, the simulating results well corresponded with those of experiments that demonstrate the constitutive equation established present good accuracy.

• Periodical: Applied Mechanics and Materials (Volumes 239-240)
• Pages: 314-319
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.239-240.314
• Online since: December 2012
• Authors: Zhi Dan Xu, Jun Jia Cui, Hai Ping Yu, Chun Feng Li
• Keywords: 3A21 Aluminium Alloy, Constitutive Relationship, Magnetic Pulse Forming

References

[1] H. Kolsky. An Investigation of the Mechanical Properties of Materials Very High Rates of Loading. Proc Phys Soc (London), 1994, 21(3): 676-700.

DOI: 10.1088/0370-1301/62/11/302

[2] H. Meng, Q. M. Li. Correlation between the Accuracy of A SHPB Test and the Stress Uniformity Based on Numerical Experiments. International Journal of Impact Engineering, 2003, 20(22): 537.

DOI: 10.1016/s0734-743x(02)00073-8

[3] A.G. Odeshi, S. Al-ameeri, M. N. Bassim. Effect of High Strain Rate on Plastic Deformation of A Low Alloy Steel Subjected to Ballistic Impact. Journal of Materials Processing Technology, 2005, (12): 385-391.

DOI: 10.1016/j.jmatprotec.2005.02.157

[4] Qiang Li, Y. B. Xue, M. N. Bassim. Dynamic Mechanical Behavior of Pure Titanium. Journal of Materials Processing Technology, 2004, 26(15): 1889-1892.

DOI: 10.1016/j.jmatprotec.2004.04.327

[5] O. S. Lee, M. S. Kimb. Dynamic Material Property Characterization by Using Split Hopkinson Pressure Bar (SHPB) Technique. Nuclear Engineering and Design, 2003, 22(6): 120-121.

DOI: 10.1016/s0029-5493(03)00189-4

[6] W. Hubert, J. R. Meyer, David S. Kleponis. Modeling the High Strain Rate Behavior of Titanium Undergoing Ballistic Impact and Penetration, International Journal of Impact Engineering, 2001, 26(1-10): 509-521.

DOI: 10.1016/s0734-743x(01)00107-5

[7] Lin, Y. C., Chen, X. M., and Liu, G., A modified Johnson-Cook model for tensile behaviors of typical high-strength alloy steel, Materials Science and Engineering, 2010, 527: 6980-6986.

DOI: 10.1016/j.msea.2010.07.061

[8] Songwon Seo, Oakkey Min, Hyunmo Yang. Constitutive Equation for Ti-6Al-4V at High Temperatures Measured Using the SHPB Technique. International Journal of Impact Engineering, 2005, 31(6): 735-754.

DOI: 10.1016/j.ijimpeng.2004.04.010

[9] G. Casalino, A.D. Ludovico. Finite element simulation of high speed pulse welding of high specific strength metal alloys. Journal of Materials Processing Technology, 2008: 301-305.

DOI: 10.1016/j.jmatprotec.2007.06.049

[10] P. Zhang, M. Kimchi, H. Shao, J.E. Gould and G.S. Daehn, Analysis of the electromagnetic impulse joining process with a field concentrator, Numiform, 2004, 1253-1258.

[11] Stern A, Aizenshtein M. Magnetic pulse welding produces high-strength aluminum welds. Sci Technol Weld Join, 2002, 7(5): 339-342.
