Improving the Error Model for POS Applicationto Airborne InSAR

Abstract:

Position and Orientation System (POS) is a technology widely used for motional error compensation of airborne InSAR. The measurement errors of inertial sensor (accelerometers and gyros) are the chief influencing factors to the precision of POS. In order to enhance the accuracy of POS, an improved SINS error model should be used in POS. In this paper, a more precise error model for SINS is developed by augmenting random walks error, first-order Markov process error, scale factor error and installation error. To validate the accuracy of the improved error model, semi physical flight simulation based on the imitation of imaging-flight route of InSAR is made to compare with the traditional SINS error model which only considering the random constant error. The simulation results show that the accuracy of the improved SINS error model is one order higher than the traditional SINS error model.

• Periodical: Applied Mechanics and Materials (Volumes 239-240)
• Pages: 521-529
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.239-240.521
• Online since: December 2012
• Authors: Lin Zhou Ting Chen, Jian Cheng Fang
• Keywords: Error Model, Kalman Filter (KF), Motion Compensation, Position and Orientation System

References

[1] Macedo K A C, Scheiber R, Moreira A, An autofocus approach for residual motion errors with application to airborne repeat-pass SAR interferometry, IEEE Transactions on Geoscience and Remote Sensing, vol 46, no 10, 2008, pp.3151-3162.

DOI: 10.1109/tgrs.2008.924004

[2] Prats P, Scheiber R, Reigber A, Andres C, Estimation of the surface velocity field of the Aletsch glacier using multibaseline airborne SAR interferometry, IEEE Transactions on Geoscience and Remote Sensing, vol 47, no 2, 2009, pp.419-430.

DOI: 10.1109/tgrs.2008.2004277

[3] Qiu Hongbo, Zhou Zhanghua, Li Yan, Establishment and analysis on high-order error model of FOG SINS, Journal of Chinese Inertial Technology, vol 15, no 5, 2007, pp.530-535. [In Chinese].

[4] Sun Hongxing, Yuan Xiuxiao, Fu Jianhong, The GPS/INS Integrated Position and Orientation in the Aerial Remote Sensing Based on the High-order INS Stochastic Error Model, Acta Geodaetica et Cartographica Sinica, vol 39, no 1, 2010, pp.28-33.

[5] Yigiter Yukse, Naser El-Sheimy, Aboelmagd Noureldin, Error Modeling and Characterization of Environmental Effects for Low Cost Inertial MEMS Units, IEEE Position Location and Navigation Symposium, Indian Wells, CA, USA, May 2010, pp.598-612.

DOI: 10.1109/plans.2010.5507180

[6] Xu Zhigang, Xin Liming, Zhao Mingyang, Error Modeling of A New Kind of Plane Movement Position and Attitude Measuring Equipment, IEEE Automation and Logistics, Jinan, China, Aug 2007, pp.2700-2705.

DOI: 10.1109/ical.2007.4339038

[7] Han Songlai, Wang Jinling, Quantization and Colored Noises Error Modeling for Inertial Sensors for GPS/INS Integration, IEEE Sensors Journal, vol 11, no 6, 2011, pp.1493-1503.

DOI: 10.1109/jsen.2010.2093878

[8] Blankinship K. G, A general theory for inertial navigator error modeling, IEEE Position, Location and Navigation Symposium, Monterey, CA, May 2008, pp.1152-1166.

DOI: 10.1109/plans.2008.4570002

[9] Ding Guoqiang, Zhou Weidong, Study on Error Modeling Methods of Strap-Down INS and Their Relations, IEEE Information and Computing Science, Manchester, May 2009, pp.341-344.

DOI: 10.1109/icic.2009.291

[10] Xu Guoqiang, Meng Xiuyun, The MEMS IMU Error Modeling Analysis Using Support Vector Machines, IEEE Knowledge Acquisition and Modeling, Wuhan, China, vol 1, Nov-Dec 2009, pp.335-337.

DOI: 10.1109/kam.2009.287

[11] Naoyuki Tamaru, Hanako Sato, Minae Tokumitsu, Novel Estimation Method of Current State Variables for Time Delay System Using a Kalman Filter with Dual Models-Influence of Modeling Error, IEEE Industrial Electronics Society, Nagoya, Japan, vol 2, Oct 2000, pp.789-794.

DOI: 10.1109/iecon.2000.972223

[12] Yuan Gannan, Yuan Kefei, Zhang Hongwei, A Variable Proportion Adaptive Federal Kalman Filter for INS/ESGM/GPS/DVL Integrated Navigation System, IEEE Computational Sciences and Optimization, Yunan, China, April 2011, pp.978-981.

DOI: 10.1109/cso.2011.63

[13] Fakharian A, Thomas Gustafsson, Mehrfam M, Adaptive Kalman Filtering Based Navigation: An IMU/GPS Integration Approach, IEEE Networking, Sensing and Control, Delft, Netherlands, April 2011, pp.181-185.

DOI: 10.1109/icnsc.2011.5874871
