Study on the Dynamic Character of the Six-Axis Heavy Force Sensor

Abstract:

Six-axis heavy force sensor will be used to measure the dynamic load of the heavy load equipment. Therefore, the dynamic character of the six-axis heavy force sensor is important. In this paper, a six-axis heavy force sensor based on the Stewart platform is developed. A dynamic measurement system is established to measure the dynamic character of the six-axis heavy force sensor. The hammer impact method is used to measure the natural frequency of the six-axis heavy force sensor. The power spectrum analysis of each channel is conducted. And the natural frequency of each channel is obtained.

• Periodical: Applied Mechanics and Materials (Volumes 241-244)
• Pages: 938-942
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.241-244.938
• Online since: December 2012
• Authors: Sheng Lin, Xiao Yu Wang, Zhen Yuan Jia
• Keywords: Dynamic Character, Heavy Force Sensor, Six-Axis

References

[1] T. Yoshikawa, T. Miyazaki: IEEE International Conference on Robotics and Automation, (New Orleans 1989).

[2] M. Kaneko, T. Nishihara: IEEE/RSJ International Conference on Intelligent Robots and Systems, (Yokohama 1993).

[3] D.R. KERR: Journal of Mechanisms Transmissions and Automation in Design-Transactions of the ASME Vol.111 (1989), pp.5-28

[4] Z. Y. Jia, S. Lin, W. Liu: Measurement. Vol. 43 (2010), pp.329-335
