A Multi-Input FFFB Control Algorithm for Railway Rapid Transit Vehicle Speed Regulation

Abstract:

The purpose of this research is to develop a multi-input control algorithm for the speed regulation of railway transit vehicle. The Taipei railway transit vehicle is chosen as the simulation object in this research. This transit vehicle has three carts and is push-pull type; only the first and the last carts are empowered. The control algorithm is to calculate the appropriate driving forces for the power units such that vehicle can follow a specified speed pattern. A feed-forward and feed-back control algorithm is designed to achieve this purpose. In the system, a dynamics variable observer is also developed to reduce required sensors for the controller. The results show that the developed controller is suitable for this purpose and the observer achieves acceptable observation quality for the controller application.

• Periodical: Applied Mechanics and Materials (Volumes 253-255)
• Pages: 2041-2046
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.253-255.2041
• Online since: December 2012
• Authors: Chiu Feng Lin, Chii Chung Cheng
• Keywords: Feed-Back Control, Feed-Forward Control, Railway Transit Vehicle, Speed Tracking

References

[1] Daddario E.Q., De Simone D.V., Krambles G.(1976), Automatic train control in rail rapid transit, Office of Technology Assessment, USA.

[2] Gordon, S.P., Williams P.J. (1999), Train control optimization, SIAG/OPT View-and-News, Vol.10, No.1.

[3] Lockyear, M.J.(1996), Changing track; moving-block railway signaling, IEE Review, pp.21-25.

DOI: 10.1049/ir:19960110

[4] Cheng, C.M., Rees, N.W., Chan, A. (1998), Fuzzy speed control of a coal train, Proceedings of the 1998 International Conference on Control. Part 1(of 2), UK, pp.525-530.

[5] Franke, R., Terwiesch, P.,Meyer, M. (2000), An algorithm for the optimal control of the driving of trains, 39th IEEE Confernce on Decision and Control, NSW, Vol.3, pp.2123-2128.

DOI: 10.1109/cdc.2000.914108

[6] Andrew, H. I. (1986), Railway Traction: The Principles of Mechanical and Electrical Railway Traction, Elsevier Publishing Company.

[7] Atala, O.M. Brill, J.C., and Carson, J.S. (1992), A general rapid transit simulation model with both automatic and manual train control, Proceeding of 1992Winter Simulation Conference, pp.1307-1311.

DOI: 10.1145/167293.167922

[8] Brun, E., and Salpears, T. (1991), Train operations comuter simulation case study: single-tracking operations for Philadephia's market Frankford subway elevated rail rapid transit line, Transportation Research Record 1308. pp.8-5.

[9] Kikuchi, S. (1991), A simulation model of train travel on a rail transit line. Journal of Advanced Transportation, V. 25, N. 2, pp.211-224.

DOI: 10.1002/atr.5670250206

[10] AREA (1987), Manual for Railway Engineering, American Railway Engineering Association, U.S.A.

[11] Ashish, T.(2002), Modern Control Design With MATLAB and SIMULINK, John Wiley & Sons Ltd., England.
