A Study on Bearing Characteristics of Horizontally-Loaded Short Piles in 750kV Transmission Line on Loess Foundation

Abstract:

For the angle tower foundation of 750kV transmission line, the overturning effect caused by wire tension is a control factor of tower foundation design. The pile foundation on loess was taken as a research object in this study, where two typical regions along 750kV Lanzhou - Tianshui - Baoji transmission line were selected to carry out the site full-size horizontal static load test. Through the arrangement of displacement sensors and earth pressure cells around piles, the load-displacement curve of pile lateral soil under horizontal loads was obtained as well as the distribution law of soil stress at different locations of the pile. Based on the "m" method, the soil stress at different locations of the pile was calculated. The results showed that the calculated results were well consistent with experimental results. This research work can provide a theoretical basis and design guidance for tower foundation selection and design optimization of 750kV transmission line.

• Periodical: Applied Mechanics and Materials (Volumes 256-259)
• Pages: 458-462
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.256-259.458
• Online since: December 2012
• Authors: Qiang Cui, Wen Zhi Yang, Sheng Hui Liu, Xian Long Lu
• Keywords: “m” Method, 750kV Transmission Line, Horizontally Load, Loess Soil, Short Pile

References

[1] Zhu Yanpeng, Zhang Anjiang, Wang Xiuli. Power series solution of internal force and deformation of piles with m-method. Journal of Gansu University of Technology, 1997, 23(3): 77-82.

[2] Zhao Minghua, Hou Yunqiu, Cao Xiren. Study on the Behavior of Inclined Loading Piles. Journal of Hunan University. 1997, 24(2): 98-109.

[3] Wang Mei, Lou Zhigang, Li Jianxiang, Zhao Jing. Nonlinear analysis of m, method for single pile under lateral loading. Rock and Soil Mechanics. 2002, 23(1): 23-30.

[4] Zhao Dean, Zheng Jing, Li Shuangyang, Chen Zhiming, etc. Formula for Calculation of Anti-Slip Pile with Different Compositions of k-method and m-method. Journal of Lanzhou Railway University(Natural Sciences). 2003, 22(1): 1-5.

[5] Chen Guoxing, Han Aimin, Zai Jingming. Discussion and modification on the computing method of horizontal bearing capacity of the technical code for building pile foundations in China. Journal of Nanjing Architectural and Civil Engineering Institute. 1998, 4: 7-14.

[6] Gan Su Electric Power Design Institute. Investigation report of engineering geological condition of gravel ground soil in field test site. 2009 (in Chinese).

[7] The Professional Standards Compilation Group of People' s Republic of China. Technical Code for Building Pile Foundation (JGJ 94-2008) [S]. Beijing: China Architecture and Building Press，(2009).

[8] The Professional Standards Compilation Group of People's Republic of China. Technical Code for testing of building foundation piles (JGJ 106-2003) [S]. Beijing: China Architecture and Building Press, (2003).
