Effect of Exhaust Nozzle Diameter on Internal Flow Field Characteristics in Base Bleed Unit Simulator

Abstract:

For the optimal design of base bleed unit, a 2D-axisymmetric unsteady model was established and the effects of different exhaust nozzle diameters on the internal flow field were studied. Results show that the larger the exhaust nozzle is, the higher the depressurization rate and the mass flux are at the earlier stage of depressurization, and the lower the pressure, the temperature, the density in the base bleed unit and the flow rate at the nozzle outlet are. But at the later stage, the depressurization rate and the mass flux are smaller instead. The radial temperature is generally unchanged in most part far from the burning surface and increases near the burning surface at the earlier stage of depressurization, whereas it is lowest at the axis and rises up quickly along the radial direction at the later stage. The radial density distributes just oppositely.

You might also be interested in these eBooks

Materials, Mechanical Engineering and Manufacture

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 268-270)

Pages:

1128-1133

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.268-270.1128

Citation:

Cite this paper

Online since:

December 2012

Authors:

Yong Jie Cao, Yong Gang Yu, Rui Ye, Yu Rong Zhang

Keywords:

Base Bleed Unit, Composite Base Bleed Charge, Internal Flow Field, Transient Depressurization

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] X. F. Guo, in: Exterior Ballistics of Base Bleed Projectile, editied by National Defense Industry Press, Beijing (1995), in Chinese

Google Scholar

[2] C Y Lu, Y H Zhou, Y G Yu: Chinese Journal of Energetic Materials, Vol. 15, No. 6 (2007), p.587, in Chinese

Google Scholar

[3] C Y Lu, Study on Characteristics of Unstable Combustion of Base Bleed Unit, edited by Doctoral Disseratation of Nanjing University of Science and Technology (2009), in Chinese

Google Scholar

[4] X S Wu, J Chen, D Wang, et al, in: Numerical Simulation of Working Process of Solid Rocket Engine, editied by High Education Press, Beijing (2006), in Chinese

Google Scholar

[5] K K Kuo, M Summerfield, in: Fundamentals of Solid Propellant Combustion, traslated by R G Zhu, G J Yu, M L Lian, et al, edited by China Astronautics Press, Beijing (1994), in Chinese

Google Scholar
