Development of Flexible Rolling Device for 3D Plate

Abstract:

To effectively form three-dimensional sheet metal parts with various curvatures produced in small quantities, flexible rolling forming, a new flexible forming method is being developed. Firstly, concept of the flexible rolling forming is introduced and its characteristics and working principle are analyzed by the combination of conventional rolling and multi-point forming. Secondly, the equipment design scheme of flexible rolling forming is put forward and the relevant device is developed. Thirdly, the feasibility and practicality of flexible rolling forming are verified by rolling several typical three-dimensional surface parts such as spherical and saddle surface parts by self-developed device. Finally, verifies the reasonableness of the device and at the same time possesses the important guiding significance to the research and development of practical flexible rolling forming equipment.

• Periodical: Applied Mechanics and Materials (Volumes 271-272)
• Pages: 852-857
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.271-272.852
• Online since: December 2012
• Authors: Ren Jun Li, Ming Zhe Li, Ning Jia Qiu
• Keywords: 3D Plate, Flexible Rolling Forming, Multi-Point Forming

References

[1] E. W. Reutel, L. Zhang, P. Michaleris. A differential geometry approach to analysis of thermal forming [J]. International Journal of Mechanical Sciences, 2006, (48): 1046-1062.

DOI: 10.1016/j.ijmecsci.2006.05.012

[2] T. Wang, M. J. Platts, A. Levers. A process model for shot peen forming [J]. Journal of Materials Processing Technology, 2006, 172:159-162.

DOI: 10.1016/j.jmatprotec.2005.09.006

[3] F.Mao, J.H.Mo, S.H. Huang. Study on instability of the point bolster sheet metal dieless forming [J]. Journal of Materials Processing Technology, 2006, 176:13-18.

DOI: 10.1016/j.jmatprotec.2005.08.003

[4] Mingzhe Li, Yuhong Liu, Shizong Su, et al. Multi-point forming: a flexible manufacturing method for a 3-d surface sheet [J], Journal of Materials Processing Technology 1999 (87): 277-280.

DOI: 10.1016/s0924-0136(98)00364-1

[5] ZHANG Xing-quan, Zhang Yong-kang, ZHOU Jian-zhong, GU Yong-yu, DU Jian-jun, Research on Plastic Curvature of Plate by Laser Shock Waves [J], Acta Aeronautica Etastronautica Sinica, 2007, 1 (28): 249-252.

[6] E. P. Degarmo, J. T. Black, and R. A. Kohser, Materials and Processes in Manufacturing [M], Wiley, ISBN 0-471-65653-4, 2003.

[7] LI Mingzhe, HU Zhiqing, CAI Zhongyi, GONG xuepeng, Method of Multipoint Continuous Forming for the FreeForm Surface Parts [J]. Chinese Journal of Mechanical Engineering. 2007, 43(12):155-159.

DOI: 10.3901/jme.2007.12.155

[8] ZHONG Shi-sheng, Fuzzy Theory and Technology in the Engineering Design [M], Harbin Institute of Technology Press, Harbin, 2000.

[9] TANG Deng-yun, Robust Optimization Design of an Antenna Structure [J], Electro-Mechanical Engineering, 2007, 23 (2): 6-8.
