Hydraulic System Design and Simulation of High-Speed Railway Dynamic Test System Excitation Device

Abstract:

The existing hydraulic excitation mode of valve controlled cylinder or pump controlled motor used in the excitation device of high-speed railway dynamic test system is difficult to meet the requirements of high exciting frequency, high exciting force and high amplitude. To solve these problems, the paper puts forward a bicyclic surface hydraulic cylinder, and designs the corresponding electro-hydraulic servo excitation system. According to the test system parameters，it establishes the mathematical model of the hydraulic system. It uses Matlab/Simulink to carry out theoretical analysis and digital simulation and uses PID Tuner to adjust the PID controller parameters. The simulation results show that the hydraulic excitation system designed meets the performance requirements of the high-speed railway dynamic test system excitation device.

• Periodical: Applied Mechanics and Materials (Volumes 271-272)
• Pages: 953-957
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.271-272.953
• Online since: December 2012
• Authors: Liang Cai Zeng, Fei Long Zheng, Yuan Wan, Qiang Hua Xi
• Keywords: Excitation Device, Force Servo Control, High-Speed Railway (HSR), MATLAB/SIMULINK, PID-Tuner
