Influence Research of Recess Shape on Dynamic Effect of Hydrostatic Thrust Bearing

Abstract:

This work describes a simulation research concerning dynamic effect of multi-pad hydrostatic thrust bearing having rectangular recess, sector recess, ellipse recess and I-shaped recess in order to solve the loading capacity of the hydrostatic thrust bearing. Three-dimensional pressure field of gap fluid between the rotation worktable and the base has been computed by using the Finite Volume Method. This study theoretically analyzes the influence of recess shape on dynamic effect of the bearing according to computational fluid dynamics and lubricating theory, and the simulation results indicate that an improved characteristic will be affected by recess shape easily. Through this method, the safety of a multi-pad hydrostatic thrust bearing having different cavities can be forecasted, and the optimal loading capacity of such products can be achieved, so it can provide reasonable data for design, lubrication, experience and thermal deformation computation for hydrostatic thrust bearing.

• Periodical: Applied Mechanics and Materials (Volume 274)
• Pages: 57-60
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.274.57
• Online since: January 2013
• Authors: Xiao Dong Yu, Zhen Guo Li, De Fan Zhou, Heng Wei Li, Chun Li Gao, Zhi Xin Qiu, Bo Wu, Yan Qin Zhang, Bai Qin, Xue Zhe Dong
• Keywords: Dynamic Effect, Hydrostatic Thrust Bearing, Recess Shape, Simulation Research

References

[1] Lewis GK. Flow and load parameters of hydrostatic oil bearings of several port shapes. J. of Mech. Engg Sci. Vol. 8(1966), P 173-84.

DOI: 10.1243/jmes_jour_1966_008_022_02

[2] Satish C. Sharama , S.C. Jain and D.K. Bharuka . Influence of Recess Shape on the Performance of a Capillary Compensated Circular Thrust Pad Hydrostatic Bearing . Tribology International Volume 35, Issue6, June 2002 , P 347~356.

DOI: 10.1016/s0301-679x(02)00013-0

[3] Satish C. Sharama , S.C. Jain and D.K. Bharuka . Study of Hole-entry Hybrib Journal Bearing System Considering Combined Influence of Thermal and Elastic Effects. Tribology International Volume 36, Issue12, December 2003, P 903~920.

DOI: 10.1016/s0301-679x(03)00074-4

[4] X.D. Yu . Simulation Research on Temperature Field of Circular Recess Hydrostatic Thrust Bearing. Key Engineering Materials Volume 419-420, 2010, P 141~144.

DOI: 10.4028/www.scientific.net/kem.419-420.141

[5] X.D. Yu . Simulation Research on Temperature Field of Circular Recess Hydrostatic Thrust Bearing. Key Engineering Materials Volume 419-420, 2010, P 141~144.

DOI: 10.4028/www.scientific.net/kem.419-420.141

[6] Y.Q. Zhang. Research on Influence of Oil Recess Shapes on Carrying Capacity of Heavy Hydrostatic Bearing. 2011 International Conference on Electronic and Mechanical Engineering and Information Technology, Volume. 2, 2011, P 1083-1086, June.

DOI: 10.1109/emeit.2011.6023194

[7] Chen Bo Xian. Fluid Theory of Lubrication and Their Application (Mechanical industry press, Beijing 1991).

[8] Pang Zhi Cheng. Liquid Gas Hydrostatic Technology (Heilongjiang the people press, Harbin 1981).

[9] Wang Fu Jun. Calculation Flow Mechanics Analyses FLUENT Software Principle and Applies (Tsing Hua University press, Beijing 2004).

[10] Han Zhan, Wang Jing, Lan Xiao Ping. The FLUENT Fluid Project Simulates Calculating an Example and Applies(Press of Beijing Institute of Technology, Beijing 2004).
