Modeling and Simulation Analysis of Certain Vehicular Gatling Gun

Abstract:

To study the influence of barrel’s deformation and vehicle velocity to certain vehicular Gatling gun, a virtual simulation with rigid-flexible coupling was established by using ADAMS/Flex module based on rigid multi-body dynamics and flexible body dynamics theories. Considering the interaction of the tires and road surface, vehicle and machine gun, the dynamic analysis and calculation of exterior ballistics were completed in various vehicle velocity condition, the muzzle response characteristics and impact position were obtained. The Model is testified rational, accuracy and effective by comparing simulating results with the experimental data of the velocity and displacement of barrel, which has laid the foundation for further simulation and structural optimization.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 2467-2470
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.2467
• Online since: January 2013
• Authors: Tao Li, Rui Lin Wang, Long Bo Sheng
• Keywords: Coupled Rigid and Flex, Modeling, Simulation, Vehicular Gatling Gun

References

[1] Bo Yucheng, Wang Huiyuan, Xie Zhijian: Study on General Technique of Galting Gun. Xianyang: Gun launch and Control Journal. pp.9-15, 2006. （In Chinese）.

[2] Ma Fuqiu, Chen Yunsheng, Du Yingxian: Artillery and auto-weanpon. Beijing: Press of Beijing Science and Engineering University, 2003. （In Chinese）.

[3] Xu Cheng, Wang Yaping: Dynamics of Gun and auto-weanpon. Beijing: Press of Beijing Science and Engineering University, 2006. （In Chinese）.

[4] Zhang Benjun: Research on Dynamic Simulation of a Rifle Based on ADAMS. Shi Jiazhuang: Ordnance Engineering College, p.31, 2007. （In Chinese）.

[5] Chen Ming, Ma Jisheng, Jia Changzhi: HighVirtual Prototying of Dualpurpose Machine Gun Based on ADAMS and Simulation. Journal of System Simulation. pp.2046-2048, 2006. （In Chinese）.
