Research on an Automatic Measurement System in Wheelset Parameters

Abstract:

This paper introduces a two-dimensional roller measurement mechanism according to the requirements of locomotive wheelset parameters measurement process. This mechanism makes it possible for single measurement head to measure the dimension parameters of a wheelset on axial and radial. It puts forward some methods on reducing parameters of wheelset systematic measurement errors after analyzing the structure of measurement mechanism. Automatic measurement system made by this two-dimensional roller measurement mechanism has high measurement efficiency and accuracy, strong anti-interference ability and operational reliability. The measurement system has been successfully applied in enterprise production.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 2543-2547
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.2543
• Online since: January 2013
• Authors: Jun Xiao, Jie Qiu, Wan Fu Yang, Rong Fang
• Keywords: Contact Measurement, Error Analyses, Wheelset Parameters Measurement

References

[1] TBT 1463-2006(Technical specification for wheelsets assembly of railway locomotive) (In Chinese). (2006).

[2] Ministry of Railways of the People's Republic of China. Railway train wheelset and rolling bearing axle box assembly and inspection rules (In Chinese). China Railway Press. 2007. 7.

[3] Tong Wang, Hesheng Zhao. Application of contacting measurement technology to the wheelset profile measurement of railway freight car. Railway Locomotive & Rolling Stock Workers (In Chinese). 2006. 11.

[4] Changjie Xu, Wei Dong, Chanyu Liu. Using two rules to compensate the error occurred from inconformity with Abbe's length measurement principle (In Chinese). Optical Technique. 2002. 1.
