Study of Shear Deformation's Influence on Deflection of Continuous Composite Box-Girder Bridge with Corrugated Steel Webs

Abstract:

Taking South-to-North Water Diversion Bridge, a continuous composite box-girder bridge with corrugated steel webs, as the engineering background, the cantilever beam end’s deflection calculation formulae considering shear deformation were deduced by using energy method. Comparing with finite-element analysis (FEA) values and measured values, the formulae which considered both concentrated force and uniform load have enough accuracy. Results show that, shear deformation’s proportion is more obvious in overall deflection of such box-girders which have smaller span ratio, and it’s more than 30%. For continuous composite box-girder bridge with corrugated steel webs, contribution of shear deformation to overall deflection should not be ignored.

• Periodical: Applied Mechanics and Materials (Volumes 275-277)
• Pages: 961-965
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.275-277.961
• Online since: January 2013
• Authors: Ming Min Tang, Li Chao Su, Shui Wan
• Keywords: Cantilever-Construction, Continuous Box-Girder Bridge, Corrugated Steel Web, Deflection, Energy Method, Shear Deformation

References

[1] M. Rosignoli: J. Proceedings of the Institution of Civil Engineers, Structures and Buildings, (1999), 134(1), pp.77-85.

[2] E. Y. Sayed-Ahmed: J. Can J Civ Eng, (2001), 28(4), pp.656-672.

[3] H. J. Li, J. S. Ye, S. Wan, W. Q. Wu: J. Journal of traffic and transportation engineering, (2002), 2(4), pp.17-20. [In Chinese].

[4] M. Elgaaly, A. Seshadri: J. Journal of Structural Engineering, (1997), 123 (6), pp.783-791.

[5] J. Su, Z. Liu: J. Sino-foreign Highway, (2010), 6(30), pp.143-147. [In Chinese].

[6] R. P. Johnson, J. Cafolla: J. Proceedings of Institute of Civil Engineering Structures and Bridges, (1997), 123 (5), pp.157-164.

[7] S. Timoshenko, J. Gere, in: Mechanics of materials, edited byVan Nostrand Reinhold Company, (1972), pp.246-248, 256-257.
