The Pressure Distribution Test System of Doctors’ Hand in Laparoscopic Surgery

Abstract:

A surface pressure distribution test system of a doctor’s hand during a laparoscopic surgery based on LabVIEW was designed. The principle was that real time acquisition of data signal on multi-channel sensors, and using data acquisition card to get the feed back voltage signal from these pressure sensors, and then transferred to a PC. The test system had realized the real time processing and display of the signal on LabVIEW. The pressure detection range was 0-210g. The system could detect the surface pressure real time of the part of a doctor’s hand which contacting the surface of handle during the laparoscopic surgical procedure. This system could also make quantitative evaluation of the contact pressure on the handle of the laparoscopic instruments and provide a reference to ergonomics design of the handle.

• Periodical: Applied Mechanics and Materials (Volumes 278-280)
• Pages: 826-830
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.278-280.826
• Online since: January 2013
• Authors: Shu Yi Wang, Dong Dong Bi, Jia Kuan Zheng, Bing Cao Wang
• Keywords: Ergonomics, Laparoscopic Surgery, Pressure Sensor, Virtual Instrument (VI)

References

[1] Xiang-jun Bi. The ergonomics research of medical instruments [D]. Shang hai: The university of donghua, 2005 In Chinese.

[2] D. Buchel, R. Marvik, B. Hallabrin. et al. Ergonomics of disposable handles for minimally invasive surgery[J]. Surg Endosc 2010 (24): 992–1004.

DOI: 10.1007/s00464-009-0714-x

[3] Chao-yuan Tian. The design of cervical traction machine force sensor based on PC [D]. Department of Mechatronics Engineering, Feng Chia University, 2008. In Chinese.

[4] Hong-jun Meng. The test system of Handle the pressure distribution based on LabVIEW [D]. zhejiang: zhejiang university of technology, 2010. In Chinese.

[5] Yan-zi Zhuang. The method of Body pressure distribution measurement [J]. Chinese Journal of Sensors and Actuators 2005, 18 (2): 313-317 In Chinese.

[6] Chiuhsiang Joe Lin, Hung-Jen Chen, Ying-Chu Lo. Ergonomic Investigation of Weight Distribution of Laparoscopic Instruments[J]. Journal of Laparoendoscopic & Advanced Surgical Techniques 2011 (21): 411-415.

DOI: 10.1089/lap.2010.0369

[7] Cao Sun, Jiang-li The hand gesture recognition system based on FSR sensors [J]. Mechanical and electronic2009 (1): 43-46 In Chinese.

[8] Hua-wei Long, Yong-gang Gu. LabVIEW 8. 2. 1 and DAQ[M]. Beijing: Tsinghua University Press. 2008 In Chinese.
