Numerical Simulation of Fluid-Structure Interaction in SRM under Cold-Flow Impact

Abstract:

The process of impacting adherent casting solid rocket motor under cool-flow impact was simulated using two-way fluid-solid coupling method by ANSYS workbench14.0. In order to truly reflect the interaction between the establishment of the flow field in the cool air impact process and the SRM grain, the impact pressure to the SRM grain was provided with reference to the structure of the shock tube. The process of the establishment and spread of the flow field pressure was simulated, according to the grain deformation under the cool air impact, the maximum deformation position of the grain was determined. The relationship between the amount of grain deformation and flow field pressure gradient was summed up by observing the law of flow field pressure distribution along the axial coupling surface.

• Periodical: Applied Mechanics and Materials (Volume 281)
• Pages: 245-249
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.281.245
• Online since: January 2013
• Authors: Huan Zhang, Jun Chen, Feng Feng
• Keywords: Cold-Flow Impact, Numerical Simulation, Solid Rocket Motor (SRM), Two-Way Fluid-Solid Coupling

References

[1] John Montesano, Kamran Behdinan, David R. Greatrix, Zouheir Fawaz, Internal Chamber Modeling of a Solid Rocket Motor: Effects of Coupled Structural and Acoustic Oscillations on Combustion, Journal of Sound and Vibration 311 (2008) 20-38.

DOI: 10.1016/j.jsv.2007.08.030

[2] Bo Han, Changsheng Zhou, Xiong Chen, Numerical Simulation of Fluid-Solid Coupling in Propellant Crack During Ignition, Journal of Solid Rocket Technology, 2011, 34(2): 180-183 (In Chinese).

[3] Yufang Wang, Bingyi Zhang, Transient Numerical Simulation Study of The Shock Tube, Metrology & Measurement Technology, 2009, 29: 23-24, 39 (In Chinese).

[4] Jinsheng Xu, Yutao Ju, Jian Zheng, Acquisition of the Relaxation Modulus of Composite Solid Propellant, Chinese Journal of Explosive and Propellants, 2011 (5): 58-62 (In Chinese).

[5] Qi Cao, Jinxian Li, Jinlan Tang, Numerical Analysis of Fluid-Structure Interaction in Ignition Process for Solid Rocket Motor with Radial Wing Slot, Computer Simulation, 2009 12(26): 29-33 (In Chinese).
