The Geothermal Field Analysis of Cooling and Heating Load Imbalance for GSHP

Abstract:

This paper developed a heat transfer model of the underground pipe group to study the effect of cooling and heating load imbalance to geothermal field. The results show that, there are the approximate linear relationship between average soil temperature and the total heat flow provided by GSHP system to the soil during the whole running period. The temperature of soil restoration ratio is less than the heat flux ration in the spring and autumn. Simulation results show that when heating/ cooling load equal to 0.5 and the heating flux for the bore hole are 60w/m and -40w/m in the Summer and Winter respectively, after this system run 12 months and 10 hours every day, the average soil temperature around borehole will increase 0.48°C, and the soil close borehole temperature will increase 1.3°C than the initial soil average temperature with the value of 17.6°C, which make GSHP not be efficiently for long term running. The results is hoped to be useful for GSHP design and long term running.

• Periodical: Applied Mechanics and Materials (Volume 281)
• Pages: 533-536
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.281.533
• Online since: January 2013
• Authors: Xiao Hong Zheng, Lei Zhang, Wen Qing Liang, Hua Qian
• Keywords: Average Soil Temperature, Cooling Imbalance, Ground Source Heat Pump (GSHP), Heat Transfer of Underground Pipe Group, Heating Imbalance

References

[1] A. M Omer. Ground-source heat pumps systems and applications, Renewable and Sustainable Energy Reviews, 2 (2008) 344-371.

DOI: 10.1016/j.rser.2006.10.003

[2] Chiasson, A. Advances in modeling of ground-source heat pump systems .M.S. Thesis, School of Mechanical and Aerospace Engineering, Oklahoma State University. (1999).

[3] Cai Jingjing, Chen Rudong. Application analysis of hybrid ground source heat pump system in hot summer and cold winter region. Refrigeration Technology. 29 (2009) 15-20.

[4] Li Kaiyuan. Research on the Operating Characteristic of Ground Source Heat Pump Based on the Temperature Field of a Group of under Ground Heat Exchangers. Master's degree thesis. Hebei University of Engineering. (2007).

[5] Genk Yavuzturk. Modeling of vertical ground loop heat exchangers for ground source heat pump systems [D]. Oklahoma：Oklahoma State University. (1999).

[6] Yu Bin, Wang Fenghao, Yan Liang. Research on influence of space and arrangement between boreholes on the multi-pipe heat exchanger of GSHP. Refrigeration and Air-Conditioning. 10 (2010) 31-34.

[7] Breger D S, et, al. Thermal energy storage in the ground: Comparative analysis of heat transfer modeling using U-tubes and boreholes[J]. Solar Energy, 56 (1996) 493-503.

DOI: 10.1016/0038-092x(96)00013-8

[8] Tao Wenquan. Numerical heat transfer. Xi'an Jiaotong University Press. (2004).
