Design of Solar Towers for Extreme Storm Conditions and for Vortex Excitation

Abstract:

The structure of Solar Updraft Towers is basically a circular cylinder, which may turn into a hyperboloid at lower levels in order apply benefits of shape strengthening. The height of the tower is up to 1.5 km and it is usually designed as a thin reinforced concrete shell. The wind action is the main natural hazard, which plays a decisive role for the feasibility of the technology. An extensive wind tunnel investigation has been recently performed at WiSt laboratory at Ruhr-University Bochum (Germany) and at Criaciv laboratory at University of Florence (Italy). The tests highlighted in no-efflux conditions (out-of-use of the power plant) a new phenomenon egarding cross-wind loads, induced by a bi-stable and asymmetric flow distribution. It is created by compartments between stiffening rings along the tower and enhanced by a strong interaction with free-end flow structures at the top of a finite length circular cylinder. A proper positioning of the rings should allow to avoid this phenomenon.

• Periodical: Applied Mechanics and Materials (Volume 283)
• Pages: 35-39
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.283.35
• Online since: January 2013
• Authors: Francesca Lupi, Hans Juergen Niemann, Claudio Borri, Udo Peil
• Keywords: Bistable Asymmetric Flow, Circular Cylinder of Finite Length, Dynamic Wind Action, Stiffening Rings, Vortex Shedding, Wind Load

References

[1] Goldack, A., 2004. Tragverhalten und Aussteifung hoher Stahlbetonrohren fuer Aufwindkraftwerke (Load-bearing behaviour and stiffening of high-rise RC-tubes for updraft power plants). Dissertation, University of Stuttgart.

[2] Harte R., van Zijl G.P.A.G. , 2007. Structural stability of concrete wind turbines and solar chimney towers exposed to dynamic wind action. Journal of Wind Engineering and Industrial Aerodynamics, 95, 1079-1096.

DOI: 10.1016/j.jweia.2007.01.028

[3] Harte R., Graffmann M., Wörmann R., 2010. Progress in the structural design of solar chimneys, SCPT2010, Proc. 2nd Int. Conf. Solar Chimney Power Tech., Bochum, Germany.

[4] Krätzig W.B., Harte R., Wörmann R., 2008. Large shell structures for power generation technologies. Proc. of the 6th Int. Conf. IASS-IACM, Cornell University, Ithaca, NY, USA.

[5] Krätzig W.B., Harte R., Montag U., Graffmann M., 2010. On structural engineering problems of solar updraft chimneys. Proceedings of the 4th Int. Conf. Structural Engineering, Mechanics and Computation, Cape Town, South Africa.

[6] Lupi F., 2009. Structural behaviour, optimization and design of a solar chimney prototype under wind loading and other actions. Master Thesis, University of Florence (within a cooperation with Ruhr University Bochum).

[7] Lupi F., Borri C., Krätzig W.B., Niemann H. -J., 2011. Solar Updraft Power Plant technology: basic concepts and structural design". In Encyclopedia Online of Life Support Systems (EOLSS) developed under the auspices of the UNESCO, Eolss Publishers, Oxford, UK.

[8] Lupi, F., Borri, C., Niemann, H. -J., Peil U., 2011. Non-conventional wind loading on ultra-high Towers in Solar Updraft Power Plants, Int. Journal of shell and space structures, 257-264.

[9] Niemann H. -J., Höffer R., 2007. Wind loading for the design of the solar tower. Proceedings of the 3rd Int. Conf. Structural Eng., Mechanics and Computation, Cape Town, South Africa.

[10] Niemann, H. -J., 2009. A Refined Approach to Wind Loading for the Design of the Solar Tower", CICIND Report, 25 (2).

[11] Niemann H. -J., Lupi F., Höffer R., Hubert W., Borri C., 2009. The solar updraft power plant: design and optimization of the tower for wind effects. Proceedings of the 5th European and African Conference on Wind Engineering EACWE5, Florence, Italy.

[12] Schlaich J., 1995. The Solar Chimney, Electricity from the Sun, Edition Axel Menges, Stuttgart.
