Quasi-Static Step Number Determination Method of a Quadruped in Step Crossing

Abstract:

Legged living creatures can move on any kinds of terrain with good adaptability. They read the terrain conditions and repeat inherent or acquired obstacle crossing sequences, which can be imitated mechanically for the design of a Quadruped. For the prototype model and the step, four corner distances are determined according to the desired body angle and the continuous locomotion sequences are determined. Also, the requirements to satisfy three conditions for step-down are introduced, which makes it possible to determine the exact number of steps in the second phase of step-down. Since step-up is the reverse of step-down, all the governing parameters are the same and the locomotion sequences of step-down are also the reverse of step-up, except for the case of walking-down by gravity. The dimensions of a suggested quadruped are used to calculate the crossing performance for the purpose of comparison.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 1904-1908
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.1904
• Online since: January 2013
• Authors: Sung Ho Park, Dong Pyo Hong
• Keywords: Center of Gravity, Corner Distance, Duty Factor, Gait, Pitch, Quadruped, Stability, Stroke, Support Phase, Transfer Phase, Vertical Range, Vertical Step

References

[1] P. G. Newcastle: La methode et l'evention nouvelle de dresser les chevaux, Anvers., cited by Muybridge(1957).

[2] R. M. Alexander and A. S. Jay: Estimates of Energy Cost for Quadrupedal Running Gaits, J. of Zoology(1980), pp.153-170.

[3] B. S. Choi and S. M. Song: Fully Automated Obstacle Crossing Gaits for Walking Machines, IEEE J. of Robotics and Automation, Vol. 2(1988), pp.802-807.

DOI: 10.1109/robot.1988.12157

[4] S. M. Song: Kinematic Optimal Design of a Six-Legged Walking Machine, Ph. D Dissertation, Ohio State University, Columbus, Ohio(1984).

[5] R. D. McGhee and G. I. Iswandhi: Adaptive Locomotion of a Multilegged Robot over Rough Terrain, IEEE Trans. On Systems, Man, and Cybernetics, Vol. SMC-9, No. 4(1979), pp.176-182.

DOI: 10.1109/tsmc.1979.4310180

[6] K. G. Pearson and R. F. Franklin: Characteristics of Leg Movements and Patterns of Coordination in Locusts Walking on Rough Terrain", Int. J. of Robotics Research, Vol. 3, No. 2(1984).

DOI: 10.1177/027836498400300209

[7] D. A. Messuri and C. A. Klein: Automatic Body Regulation for Maintaining Stability of a Legged Vehicle during Rough Terrain Locomotion, IEEE J. Robotics and Automation, RA-1(3)(1985) pp.132-141.

DOI: 10.1109/jra.1985.1087012

[8] S. H. Park and G. J Chung: Quasi-Static Obstacle Crossing of an Animal Type Four-Legged Walking Machine", Robotica, Vol. 18(2000), pp.519-533.

DOI: 10.1017/s0263574799002593

[9] G. H. Choi, J. M. Yoo and Y. T. Kim: A Study on the Walking Stability of the Quadruped Robot with WBO, J. of the Korea Society of Precision Engr., Vol. 22, No. 6(2005), pp.118-126.

[10] N. W. Kim, K. W. Kim and H. C. Sin: Static Gait Generation of Quadruped Walking Robot, Trans. Of the Korean Society of Machine Tool Engr., Vol. 16, No. 6(2007).

[11] B. Katie and T. Russ: Dynamically Diverse Legged Locomotion for Rough Terrain, Proceedings of the IEEE/RAS Int. Conf. on Robotics and Automation(ICRA), Video Submission(2009).

DOI: 10.1109/robot.2009.5152757

[12] C. R. Shin, J. A. Kim and J. H. Park: Control Algorithm for Stable Galloping of Quadruped Robots on Irregular Surfaces, J. of Mech. Sci. and Tech., Vol. 34. No. 6(2010), pp.659-665.

DOI: 10.3795/ksme-a.2010.34.6.659
