The Effect of the Different Core Layer on Polymer Asymmetric Bragg Couplers

Abstract:

In this work, we successfully developed a process to fabricate dual-channel polymeric waveguide filters based on an asymmetric Bragg coupler using holographic interference techniques, soft lithography, and micro molding. At the cross- and self-reflection Bragg wavelengths, the transmission dips of approximately –16.5 and –11.7dB relative to the 3dB background insertion loss and the 3dB transmission bandwidths of approximately 0.6 and 0.5nm were obtained from an ABC-based filter. The transmission spectrum overlaps when the effective index difference between two single waveguides is less than 0.0025.

You might also be interested in these eBooks

Innovation for Applied Science and Technology

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 284-287)

Pages:

2821-2825

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.284-287.2821

Citation:

Cite this paper

Online since:

January 2013

Authors:

Fang Chang Hsu, Che Yi Liao, Xiao Han Yu, Xuan Ming Lai, Chi Ting Ho

Keywords:

Coupler, Effective Refractive Index, Filter, Grating, Waveguide

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A. Yariv, Introduction to Optical Electronics, 3rd edition, (H. Rinehart & Winston, New York, 1984).

Google Scholar

[2] J. C. Lötters, W. Olthuis, P. H. Veltink, and P. Bergveld, The mechanical properties of the rubber elastic polymer polydimethylsiloxane for sensor applications, J. Micromech. Microeng. 7(3), 145–147 (1997).

DOI: 10.1088/0960-1317/7/3/017

Google Scholar

[3] M. Greenberg, and M. Orenstein, Unidirectional complex grating assisted couplers, " Opt. Express 12(17), 4013–4018 (2004), http: /www. opticsexpress. org/abstract. cfm, URI=OPEX-12-17-4013.

DOI: 10.1364/opex.12.004013

Google Scholar

[4] M. Rossi, H. Rudmanr, B. Marty, and A. Maciossek, Wafer-scale micro-optics replication technology, in Lithographic and Micromaching Techniques for Optical Component Fabrication II, E. -B. Kley and H.P. Herzid, eds., Proc. SPIE 5183, 148–154 (2003).

DOI: 10.1117/12.507769

Google Scholar

[5] P. Nussbaum, I. Philipoussis, A. Huser, and H. P. Herzig, Simple technique for replication of micro-optical elements, Opt. Eng. 37(6), 1804–1808 (1998).

DOI: 10.1117/1.601799

Google Scholar
