Multimode-Interference-Based Waveguide Crossing in Two-Dimensional Cubic Photonic Crystal

Abstract:

A novel design of photonic crystal waveguide crossing based on multimode-interference (MMI) structure is proposed. Two structures of difference device lengths are simulated and studied. The proposed structures have high transmission efficiency for a wide bandwidth. The crosstalk is -26dB with device length of 12 lattice periods and -39dB with device length of 24 lattice periods. The plane wave expansion method and finite-difference time-domain method are used to calculate the modal dispersion curve and field propagation, respectively. The proposed MMI-based waveguide crossing has the potential to be practical in high-density optical integrated circuits.

You might also be interested in these eBooks

Innovation for Applied Science and Technology

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 284-287)

Pages:

2876-2879

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.284-287.2876

Citation:

Cite this paper

Online since:

January 2013

Authors:

Yih Bin Lin, Jen Hao Cheng, Rei Shin Chen, Ting Chung Yu, Ju Feng Liu, Han Bin Lin

Keywords:

Multimode-Interference (MMI), Photonic Crystal (PC), Waveguide Crossing

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] H. Liu, H. Tam, P.K.A. Wai, and E. Pun, Optics Communications Vol. 241 (2004), p.99.

Google Scholar

[2] T. Fukazawa, T. Hirano, F. Ohno and T. Baba, Japanese Journal of Applied Physics Vol. 43 (2004), p.646.

Google Scholar

[3] C. H. Chen and C.H. Chiu, IEEE J. Quantum Elec. Vol. 46 (2010), p.1656.

Google Scholar

[4] S. G. Johnson, C. Manolatou, S. Fan, P. R. Villeneuve, J. D. Joannopoulos and H. A. Hous, Optics Letters Vol. 23 (1998), p.1855.

Google Scholar

[5] S. F. Mingaleev, M. Schillinger, D. Hermann and K. Busch, Optics Letters Vol. 29 (2004), p.2858.

Google Scholar

[6] Y. Jiao, S. F. Mingaleev, M. Schillinger, D. A. B. Miller, S. Fan, and K. Busch, IEEE Photonics Tech. Lett. Vol. 17 (2005), p.1875.

Google Scholar

[7] S. G. Johnson and J. D. Joannopoulos, Opt. Express Vol. 8 (2001), p.173.

Google Scholar

[8] A. Taflove and S. C. Hagness, Editor, Computational Electrodynamics: The Finite-Difference Time-Domain Method, Third Ed., Artech House, Norwood, (2005).

Google Scholar

[9] T. Liu, A. R. Zakharian, M. Fallahi, J. V. Mononey, and M. Mansuripur, J. Lightwave Tech. Vol. 22 (2004), p.2842.

Google Scholar
