Numerical Model of Journal Bearing Lubrication Considering a Bending Stiffness Effect

Abstract:

An analysis for operating characteristics of journal bearing lubrication system is performed based on the numerical model. Dynamic bearing lubrication characteristics such as oil film pressure and thickness distribution can be analyzed through a numerical model with an integration of elastohydrodynamics and multi-flexible-body dynamics (MFBD). In particular, the oil film thickness variation by elastic deformation is considered in the elastohydrodynamic analysis by applying the bending stiffness effect of journal. And the oil film thickness variation by the bending stiffness effect is applied to the fluid governing equations to calculate the oil film pressure in the elastohydrodynamic lubrication region. A series of process proposed in this study is available for the analysis of realistic elastohydrodynamic lubrication phenomenon. Also, a numerical example for the journal bearing lubrication system is demonstrated and compared with the experimental results. The numerical results considering the bending stiffness effect show a good agreement with the experimental results.

• Periodical: Applied Mechanics and Materials (Volumes 284-287)
• Pages: 854-860
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.284-287.854
• Online since: January 2013
• Authors: Juh Wan Choi, Seong Su Kim, Sung Soo Rhim, Jin Hwan Choi
• Keywords: Bending Stiffness Effect, Elastohydrodynamic, Journal Bearing, Lubrication, MFBD

References

[1] C.M. Taylor: Engine Tribology, Elsevier science publishers B. V., pp.75-87. (1993).

[2] K.P. Oh and P.K. Goenka: The elastohydrodynamic solution of journal bearings under dynamic loading, ASME, Journal of tribology, Vol. 107, No. 3, pp.389-395. (1985).

DOI: 10.1115/1.3261091

[3] G.A. Labouff and J.F. Booker: Dynamically loaded journal bearings: a finite element treatment for rigid and elastic surfaces, ASME, Journal of tribology, Vol. 107, No. 4, pp.505-515. (1985).

DOI: 10.1115/1.3261117

[4] O. Reynolds: On the Theory of Lubrication and its Application to Mr. Beauchamp Tower's Experiments, Including an Experimental determination of the Viscosity of Olive Oil, Phil. Trans. Roy. Soc., Vol. 177, pp.157-234. (1886).

DOI: 10.1098/rstl.1886.0005

[5] D. Peiskammer, H. Riener, M. Prandstotter and M. Steinbatz: Simulation of motor components : integration of EHD - MBS - FE - Fatigue, ADAMS User Conference. (2002).

[6] H. Riener, M. Prandstotter and W. Witteveen: Conrod Simulation: Integration on EHD - MBS - FE - Fatigue, ADAMS User Conference. (2001).

[7] J. Choi: A Study on the Analysis of Rigid and Flexible Body Dynamics with Contact, PhD Dissertation, Seoul National University, Seoul. (2009).

[8] D. Zhu and H.S. Cheng: Effect of surface roughness on the point contact EHL. Trans. ASME, J. Tribology, 110, 32-37. (1998).

DOI: 10.1115/1.3261571

[9] J.A. Greenwood and J.H. Tripp: The Contact of Two Nominally Flat Rough Surfaces, Proc. Instn. Mech. Engrs., Vol. 185, Part 1, No. 48, p.625–633. (1971).

DOI: 10.1243/pime_proc_1970_185_069_02

[10] R.H. Sabersky, A.J. Acosta and E.G. Hauptmann: Fluid Flow : A First Course in Fluid Mechanics, Third Edition, Maxwell Macmillan International Editions. (1989).

[11] R. Gohar: Elastohydrodynamics, Second Edition, Imperial College Press. (2001).

[12] S. Jang and Y. Park: Study on the Effect of aerated lubricant on the journal trace in the engine bearing clearance, International Journal of Automotive Technology, Vol. 6, No. 4, p.421−427. (2005).

[13] S.V. Patankar: Numerical Heat Transfer and Fluid Flow. Hemisphere. Washington. (1980).

[14] J. Choi, S.S. Kim, S.S. Rhim and J.H. Choi: Numerical Modeling of Journal Bearing Considering both Elastohydrodynamic Lubrication and Multi-Flexible-Body Dynamics, International Journal of Automotive Technology, Vol. 13, No. 2, pp.255-261. (2012).

DOI: 10.1007/s12239-012-0022-7

[15] RecurDynTM Manual, http: /www. functionbay. co. kr, FunctionBay, Inc. (2012).

[16] Y. Okamoto, K. Kitahara, K. Ushijima, S. Aoyama, G.J. Jones and H. Xu: Effects of the Design Parameters on Wear and Fatigue of Engine Bearings by EHL Analysis, Seoul 2000 FISITA World Automotive Congress, June 12-15. (2000).

DOI: 10.4271/1999-01-1514
