Study on Similar Skills of Dynamic Model Test Concerning Fluid-Structure Interaction for Water-Conveyance Tunnel in Soft Soil

Abstract:

Three basic types of similar relationship between the prototype and the model for dynamic structural model test and dynamic destructive model test were proposed in corresponding literatures. At the time the situation where various similar relationships are applicable and the technique to ensure similarity for the different goal was discussed. Here the numerical simulation of model test of water-conveyance tunnel concerning fluid-structure interaction in soft soil is studied. Based on economy and practicability of selective material for model test, the similar relationship and the technique are proposed, which are validated through the example. The results of numerical simulation show: under the specific conditions, data of the model test can completely transfer to those of the prototype by use of this type of similar skill, and get more useful information. Some new ideas are introduced to keep the similarity of the hydro-structure structures.

• Periodical: Applied Mechanics and Materials (Volumes 29-32)
• Pages: 1458-1463
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.29-32.1458
• Online since: August 2010
• Authors: Jin Yun Liu, Jian Yun Chen
• Keywords: Fluid Structure Interaction (FSI), Numerical Simulation of Dynamic Model Test, Similar Skill, Water-Conveyance Tunnel

References

[1] DONLON W P, HALL J F. Shaking table study of concrete gravity dam monoliths. Earthquake Engineering Structure Dynamics, Vol. 20 (1991), pp.769-786.

DOI: 10.1002/eqe.4290200805

[2] MIR R A, TAYLOR C A. An experimental investigation into earthquake induce failure of medium to low height concrete gravity dam. Earthquake Engineering Structure Dynamics, Vol. 24 (1995), pp.378-393.

DOI: 10.1002/eqe.4290240306

[3] LIN G, ZHOU J, FAN C Y. Dynamic model rupture test and safety evaluation of concrete gravity dams. Dam Engineering, Vol. IV (1993), pp.173-186.

[4] LIN Gao. Study on model similitude of arch dam vibration. Journal of Hydraulic Engineering, Vol. 1 (1958), pp.80-104.

[5] LIN Gao, ZHU Tong, LIN Bei. Similarity technique for dynamic structural model test. Journal of Dalian University of Technology, Vol. 40(2000), pp.1-8.

[6] CHEN Yue-qing, LV Xi-lin, LI Pei-zhen, CHEN Bo, HU Zhi-li. Shaking table testing for layered soil-foundation-structure interaction system. Earthquake Engineering and Engineering Vibration, Vol. 21(2001), pp.104-112.

[7] LOU Meng-lin, WANG Wen-jian, MA Heng-chun, ZHU Tong. Study on Soil-pile-structure Interaction System by Shaking Table Model Test. Journal of TONGJI University, Vol. 29(2001), pp.763-768.

[8] Chen Yueqing, Lv Xilin, Li Peizhen, Chen Bo. Comparative study on the dynamic soil-structure interaction system with various soils by using shaking table model tests. CHINA CIVIL ENGINEERING JOURNAL, Vol. 39(2006), pp.57-64.

[9] ZHANG Shi-bao, ZHANG Cong-jiao. The experimental research the simulational material model of the culvert aqueduct of the Anyang River on the main channel of the middle route of south-to-north water transfer project. Journal of North China Institute of Water Conservancy and Hydroelectric Power, Vol. 21(2000).
