Influence of Power Supply Current in Electrical Landfill Leakage Detection Method

Abstract:

The electrical method is effective on detecting and locating leaks in geomembrane liners for landfills. If a leak exists in the liner, an anomaly in the measured potential is generated in the immediate vicinity of the leak through which electrical current is flowing. But the power supply current above the liner can affect the potential distribution. A current point source model for power supply current was set up in this paper. The potential equation induced by the point source was derived. The analysis of potential expression shows that: 1) the potential generated by the power supply current is proportional to the current size and the medium resistivity; 2) as the medium thickness increases, the potential reduces; 3) to reduce the influence of power supply current, the power supply electrode should be away from the detection area as far as possible.

You might also be interested in these eBooks

Applied Mechanics And Mechanical Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 29-32)

Pages:

2686-2691

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.29-32.2686

Citation:

Cite this paper

Online since:

August 2010

Authors:

Shao Peng Guan, Yu Ling Wang, Chang Xin Nai, Jing Cai Liu

Keywords:

High Voltage DC Method, Landfill, Leakage Detection, Power Supply Current

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D. L. Laine, and G. T. Darilek. Locating Leaks in Geomembrane Liners of Landfills Covered With a Protective Soil. Geosynthetics'93 Conference Proceedings, Canada (1993).

Google Scholar

[2] P. Colucci, and M. C. Lavagnolo. Three Years Field Experience in Electrical Control of Synthetic Landfill Liners. Proc. of the Fifth International Landfill Symposium, Italy (1995).

Google Scholar

[3] A. Rollin, M. Marcotte, T. Jacquelin, and L. Chaput. Leak Location in Exposed Geomembrane Liners Using an Electrical Leak Detection Technique. Geosynthetics '99 Conference Proceedings, USA (1999).

Google Scholar

[4] Parra J O. Electrical response of a leak in a geomembrane liner. Geophysics, vol. 53 (1988), p.1445.

DOI: 10.1190/1.1442424

Google Scholar

[5] Parra J O, Owen T E. Model studies of electrical leak detection surveys in geomembrane-lined impoundments. Geophysics, vol. 53 (1988), p.1453.

DOI: 10.1190/1.1442425

Google Scholar

[6] Yang P, Neng C, Yang G, et al. Analytical model for landfill high voltage DC leak detection. Journal of Liaoning Technical University (Natural Science Edition), vol 25 (2006), p.567.

Google Scholar
