Temperature Sensitivity Analysis of Large Span PC Concrete Box-Girder Bridge

Abstract:

Setting in the youshui Bridge Project and referring to the stipulation on the temperature gradient in current code, this aims to investigate the effects on the stress condition of concrete box-girder bridges caused by the overall heating, cooling or standard temperature changes. The process was carried out by virtue of the general finite element analysis software—MIDAS/CIVIL. The result showed that temperature would greatly affect the structural behavior of a bridge, in particular that the stress condition of the top plate is sensitive to temperature changes. It was therefore suggested that climate conditions should be taken into consideration when determining the temperature gradient values in the code.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 1060-1063
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.1060
• Online since: February 2013
• Authors: Guo Jing He, Jie Lu, Jin Yi
• Keywords: Concrete Box-Girder Bridge, Overall Heating and Cooling, Sensitivity, Temperature Gradient, Thermal Stress

References

[1] Fan L C. Bridge Engineering[M]. Beijing: China Communications Press. 2001. ( in Chinese).

[2] Fang Z, Wang J. Sun Light Thermal difference effect on long-span PC continuous box girder bridge［J］. Structural Engineers Vol. 27, No. 5. 48. Structural Analysis China Journal of Highway and Transport, 2007, 20( 1) : 62 － 67. (in Chinese).

[3] Tang Z. The Distribution on Temperature Field and Mode of Temperature Load of the Box Structure under Conditions of Field Testing and Solar Radiation[D]．Shanghai: Tongji University, 2010. ( in Chinese).

[4] Liu X F. Temperature Stress Analysis of Concrete Structures[M]. Beijing: China Communications Press, 1991. (in Chinese).

[5] Gao B B. The Study on Temperature Field and Mode of Temperature Gradient of Continuous Rigid Frame Bridge with High Piers and Long Spans[D]. Shanghai: Tongji University, 2008． ( in Chinese).

[6] Roberts-Wollman C L, Breen J E． Measurements of thermal gradients and their effects on segmental concrete bridge[J]. Journal of Bridge Engineering, 2002, 7( 3) : 166 － 174.

DOI: 10.1061/(asce)1084-0702(2002)7:3(166)

[7] Ministry of Communications of PRC. JTG D60—2004General Code for Design of Highway Bridges and Culverts[S]. Beijing: China communications Press, 2004． (in Chinese).

[8] Ministry of Communications of PRC. TB 10002． 3—2005 Code for Design on Reinforced and Pre-stressed Concrete Structure of Railway Bridge and Culverts[S]. Beijing: China Railway Publishing House, 2005. ( in Chinese).
