New Development in Relay Protection for Smart Grid – Protection Function Development

Abstract:

The requirement is that the protection relay provides early warning for the protected device in order to guarantee the system reliability and high system security after fault is cleared. The development of new protection functions for smart grid is introduced in this paper. The principles and techniques of integrated state monitoring and main protection techniques for transformers are presented. The principles and techniques of transmission cross section protection which has developed from the line overload protection technique is also presented to show its application to avoid cascading overload tripping. Finally an islanding control system is presented. In the control system the islanding center is responsible for the co-ordination, and optimization and out-of-step relays are responsible for complimentary action. The aim of islanding control is that load-generation imbalance in each island is minimized and generators in each island are not out of step any more.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 2109-2118
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.2109
• Online since: February 2013
• Authors: Pei Ding, Fei Guo, Xu Tao Wu, Xiu Guang Li, Zhen Hua Yan, Zhi Guo Hao
• Keywords: Integrated State Detection and Main Protection, Islanding Protection System, Smart Grid (SG), Transmission Cross Section Protection

References

[1] Hao Zhiguo, Research on Principle and Algorithm of Integrated System Incorporating Power Transformer Main Protection and On-line Monitoring Windings Deformation[D] Xi'an: Xi'an Jiaotong University, (2006).

[2] Li Peng, Hao Zhiguo, Zhang Baohui, etc. Leakage inductance calculation based on finite element method for power transformer and its application to winding deformation analysis [J]. Electric power automation equipment, 2007, 27(7): 49-53.

[3] Gao Jing, Wang Jianhua, Zhang Baohui, etc. On Line Identif ication Algorithm for Transformer Leakage Inductance [J], Journal of Xi'an Jiaotong University, 2008, 42(2): 199-203.

[4] Hao Zhiguo, Zhang Baohui, Chu Yunlong, etc. Study on transformer protection principle based on equivalent circuit equilibrium equation [J]. Proceedings of the CSEE, 2006, 26(10): 67-72.

[5] Hao Zhiguo, Zhang Baohui, Li Peng, etc. Study on On2l ine Detecting of Transformer Winding Deformation Based on Parameter Identif ication of Leakage Inductance [J]. High voltage engineering, 2006, 32(11)：67-73.

[6] Zhang Baohui, Yao Feng, Zhou Decai, et al．Study on security protection of transmission section and its key technologies [J]．Proceedings of the CSEE, 2006, 26(21): 1-7(in Chinese).

[7] Zhou Decai, Zhang Baohui, Yao Feng, et al．Fast search for transmission section based on graph theory[J]．Proceedings of the CSEE, 2006, 26(12): 34-41(in Chinese).

[8] YAO Feng, ZHANG Bao-hui, ZHOU De-cai, etc. Active Power Security Protection of Transmission Section and Its Fast Algorithm [J]. Proceedings of the CSEE, 2006, 26(13), 31-36.

[9] Li Yinghui, Zhang Baohui, Yu Guangliang, etc. A new method to determine splitting surfaces of power system by critical unstable mode prediction [J]. Power system technology, 2006, 30(5): 44-48 (in Chinese).

[10] WANG Cheng-gen, ZHANG Bao-hui, HAO Zhi-guo etc A Fast Method for Power System Splitting Surfaces Searching [J]. Journal of Xi'an Jiaotong University, 2009, 43(2): 90-95.

[11] WANG Cheng-gen, ZHANG Bao-hui, Shu Jin etc． A Fast Method for Power System Splitting Boundary Searching[C]. Power and energy society general meeting, Calgary, Canada, (2009).

DOI: 10.1109/pes.2009.5275588

[12] WANG Cheng-gen, ZHANG Bao-hui, Li Peng, etc A Novel Fast Searching Algorithm for Power System Self-adaptive Islanding[C]. Asia-Pacific Power and Energy Engineering Conference, Wuhan, (2009).

DOI: 10.1109/appeec.2009.4918092
