Using Dynamic Reactive Power Compensation Equipments to Enhance Low Voltage Ride-Through Capability of Fixed Speed Asynchronous Wind Farms

Abstract:

This paper presents wind energy conversion model, drive shaft’s dual-mass model and generator’s transient mathematical model for the transient analysis of fixed speed asynchronous wind generators, and analyzes the transient characteristics of the wind generators under the condition of low voltage fault. The control principles of two dynamic reactive power compensation equipments as static var compensator (SVC) and static synchronous compensator (STATCOM) are introduced. Take a wind farm consists of fixed speed asynchronous wind generators as an example, the two compensation equipments are simulated in PowerFactory/DIgSILENT to compare the effort of them on enhancing the low voltage ride-through capability of the wind farm.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 481-489
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.481
• Online since: February 2013
• Authors: Yu Lin Hu, Lei Shi, Hao Ming Liu
• Keywords: Dynamic Reactive Power Compensation, Fixed Speed Asynchronous Wind Generator, Static Synchronous Compensator (STATCOM), Static VAR Compensator (SVC), Wind Power

References

[1] Q/GDW 392—2009 Technical rule for connecting wind farm to power network [S]. Beijing, China: State Grid Corporation of China, 2009 (in Chinese).

[2] Aung Ko Thet, Hiroumi Saitoh. Pitch control for improving the low-voltage ride-through of wind farm [C]. Proceedings of Transmission & Distribution Conference & Exposition: Asia and Pacific, October 26-30, 2009: 1-4.

DOI: 10.1109/td-asia.2009.5356993

[3] WANG Hongfu, LIN Guoqing, QIU Jiaju, et al. Improvement of low voltage ride-through capability of wind farms by use of series dynamic braking resistors [J]. Automation of Electric Power Systems, 2008, 32 (18): 81-85 (in Chinese).

[4] CHI Yongning, GUAN Hongliang, WANG Weisheng, et al. Enhancement of transient voltage stability of induction generator based wind farm by SVC and pitch control [J]. Automation of Electric Power Systems, 2007, 31(3): 95-100 (in Chinese).

[5] FAN Gaofeng, CHI Yongning, ZHAO Haixiang, et al. Transient voltage stability enhancement of wind farm using STATCOM [J]. Transaction of China Electrotechnical Society, 2007, 22(11): 158-162 (in Chinese).

[6] IEEE Special Stability Controls Working Group. Static var compensator models for power flow and dynamic performance simulation [J]. IEEE Transactions on Power Systems, 1994, 8(1): 229-240.

DOI: 10.1109/59.317606

[7] ZHANG Xing, ZHANG Yunlong, YANG Shuying, et al. Low voltage ride-through technologies in wind turbine generation [J]. Proceedings of the CSU-EPSA, 2008, 20(2): 1-8 (in Chinese).

[8] Vladisiav Akhmatov. Induction generators for wind power [M]. Essex, UK: Multi-Science Publishing Company Limited, (2007).

[9] Akhmatov V, Nielsen A. H, Knudsen H Electromechanical interaction and stability of power grids with windmills [C]. Proceedings of IAESTED International Conference on Power and Energy Systems, September 19-22, 2000, Marbella, Spain: 398-405.

[10] WU Xueguang, ZHANG Xuecheng, YIN Yonghua. Application of models of the wind turbine induction generators (WTIGs) to wind power system dynamic stability analysis [J]. Power System Technology, 1998, 22(6): 68-72 (in Chinese).

DOI: 10.1109/icpst.1998.729318

[11] Marta Molinas, Jon Are Suul, Tore Undeland. Low voltage ride through of wind farms with cage generators: STATCOM versus SVC [J]. IEEE Transactions on Power Systems, 2008, 22(3): 1104-1117.

DOI: 10.1109/tpel.2008.921169

[12] LI Chun, JIANG Qirong, WANG Zhonghong. Voltage regulation stability analysis of STATCOM [J]. Proceedings of the CSEE, 2000, 20(8): 46-50 (in Chinese).

[13] ZHU Wu, CAO Ruifa. Improved low voltage ride-through of wind farm using STATCOM and pitch control [C]. Proceedings of IEEE 6th International Power Electronics and Motion Control Conference, May 17-20, 2009, Wuhan, China: 2217-2221.

DOI: 10.1109/ipemc.2009.5157771
