Wavelet Fusion Application in Water Quality Warning Based on Bio-Detection Technology

Abstract:

In water quality early warning system based on the abnormal behavior of fish, the core technology is building the fish movement model and obtaining the movement parameter based on this model. The fish body image accurate segmentation is the key to the implementation of this core technique. The single edge detection method can not accurately detect fish all edges. In the paper, the proposed solution is that the original image is firstly segmented by Canny operator and Log operator respectively and then the two segmented images are fused based on the wavelet transform. The fused image will obtain more complete target information from the two segmented images. The fish image acquired by the machine vision is processed according to the idea. The result shows that this method can obtain better edge detection effect. It will provide technical support for the live fish movement modeling.

• Periodical: Applied Mechanics and Materials (Volumes 295-298)
• Pages: 924-927
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.295-298.924
• Online since: February 2013
• Authors: Yi Hong Wang, Jun Chen, Shi Feng Tao
• Keywords: Fish Image, Fusion Image, Water Quality early Warning, Wavelet Transform (WT)

References

[1] Tang Yiping, You Sisi, etc: Development of Biological Water Quality Monitoring Equipment Based on Machine Vision, SICE-ICASE (2006), pp.3835-3839.

DOI: 10.1109/sice.2006.314672

[2] Raghav, A., Hasan, R., Mahmood, S.: History of Non Artificial Intelligence Based Biological Monitoring of River Water Quality, ICIII (2011), Vol. 3, pp.248-253.

DOI: 10.1109/iciii.2011.342

[3] Serra-Toro, C., Montoliu, R., etc: Assessing Water Quality by Video Monitoring Fish Swimming Behavior, ICPR (2010), pp.428-431.

DOI: 10.1109/icpr.2010.113

[4] Cheng-Liang Lai, Chien-Lun Chiu: Using image processing technology for water quality monitoring system, ICMLC (2011), Vol. 4, pp.1856-1861.

[5] G. Zhang, J. Jia, etc: Moving Object Extraction with a Hand-held Camera[C], ICCV (2007), pp.1-7.

[6] A. Bugeau, P. Perez: Detection and Segmentation of Moving Objects in Highly Dynamic Scenes [C]. ICCVPR (2007), pp.1-8.

DOI: 10.1109/cvpr.2007.383244

[7] L. Ladicky, C. Russell, P. Kohli, and P. H. Torr: Graph Cut Based Inference with Co-occurrence Statistics, ECCV (2010), pp.1-14.

DOI: 10.1007/978-3-642-15555-0_18

[8] Malcolm, Y. Rathi, and A. Tannenbaum: A Graph Cut Approach to Image Segmentation in Tensor Space, In Workshop on Component Analysis, CVPR (2007), pp.18-25.

DOI: 10.1109/cvpr.2007.383404
