Computer Simulation and Modelling of 3D Travelling Wave Ultrasonic Motor Using a Flexural Vibration Ring Transducer

Abstract:

This paper presents a 3D piezoelectric ultrasonic motor using a single Flexural Vibration Ring Transducer. The motor consists of three main parts, the rotor, the stator and the housing unit. The stator is a piezoelectric transducer ring made from PZT S42 material. Three steel rods and a magnet were designed to support the rotor. The rotor is a sphere of metal that rests on the stator intersecting at the tips of the steel rods and the magnet. The housing unit is made of Perspex, a transparent thermoplastic material. Longitudinal and bending vibration modes, of oscillating structures are superimposed in the motor, generating elliptical micro motions at the driving tips. Pressing the rotor against the stator tips the micro motions are converted into a 3D rotational motion, via the friction between the tips of the three rods and the rotor. The motor structures, working principles, design and finite element analysis are discussed in this paper. A prototype of the motor was fabricated and its characteristics measured. Experimental tests show typical speed of movement equal to 35 revolutions per minute, a resolution of less than 5μm and maximum load of 3.5 Newton.

• Periodical: Applied Mechanics and Materials (Volume 307)
• Pages: 31-41
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.307.31
• Online since: February 2013
• Authors: Mahmoud Shafik, B. Nyathi, S. Fekkai
• Keywords: 3D Ultrasonic Motor, Mechatronics, Piezoelectric Motor Industrial Applications

References

[1] Chunsheng Zhao, Ultrasonic motors: technologies and applications, Science Press, New York, (2011).

[2] S. Lin, An improved cymbal transducer with combined piezoelectric ceramic ring and metal ring, Elservier, China, sensors and actuators A: Physical Vol: 16 p-226-276, (2010).

DOI: 10.1016/j.sna.2010.06.022

[3] D. Engleke, B. Oehme, and J. Strackeljan, A Novel Drive Option for Piezoelectric Ultrasonic Transducers, Hindawi Publishing Corp, Modelling and Simulation in Engineering, Vol 2011, ID 910876, pp.1-6, (2011).

DOI: 10.1155/2011/910876

[4] J.S. Park, S.T. Kim, J.W. Kim, Ultrasonic linear motor using L1-B4 mode and its analysis, Jpn. J. Appl. Phys. 44 (1A) 412–416, (2005).

DOI: 10.1143/jjap.44.412

[5] Yu. G. Martynenko, I.V. Merkuryev, and V.V. Podalkov. Control of Nonlinear Vibrations of Vibrating Ring Microgyroscope. Mechanics of Solids. Vol. 43, No. 3, pp.379-390, (2008).

DOI: 10.3103/s0025654408030102

[6] J. Jiamei, and Z. Chunsheng, A novel Traveling Wave Ultrasonic Motor Using a Bar Shaped Transducer, J. Wuham University of Technology, (2008).

[7] C.H. Yun, T. Ishii, K. Nakamura, S. Ueha, K. Akashi, A high power ultrasonic linear motor using a longitudinal and bending hybrid bolt-clamped Langevin type transducer, Jpn. J. Appl. Phys. 40 3773–3776, (2001).

DOI: 10.1143/jjap.40.3773

[8] F. Zhang, W.S. Chen, J.K. Liu, Z.S. Wang, Bidirectional linear ultrasonic motor using longitudinal vibrating transducers, IEEE Trans. Ultrason. Ferroelectr. Freq. Control. 52 (1) 134–138, (2005).

DOI: 10.1109/tuffc.2005.1397358

[9] S.J. Shi, W.S. Chen, A bidirectional standing wave ultrasonic linear motor based on Langevin bending transducer, Ferroelectronics 350 102–110, (2008).

DOI: 10.1080/00150190701369958

[10] M. Shafik, J. A. G. Knight, H. Abdalla, (2001), Development of a new generation of electrical discharge texturing system using an ultrasonic motor, 13th International Symposium for Electromachining, ISEM, Spain, May 9th to 11th, , (2001).

[11] M. Shafik, J. A. G. Knight, H Abdalla, An investigation into electro discharge machining system applications using an ultrasonic motor", Proceeding of ESM, -2002 International Conference, Belfast, August 28th to 31st, (2002).

[12] M. Shafik & J. A. G. Knight, Computer simulation and modelling of an ultrasonic motor using a single flexural vibrating bar", Proceeding of ESM, 2002 International Conference, Germany, June 3rd to 5th, (2002).

[13] Shafik, M, Computer Aided Analysis and Design of a New Servo Control Feed Drive for EDM using Piezoelectric USM, PhD Thesis, De Montfort University, Leicester, UK, (2003).

[14] M. Shafik, E. M. Shehab and H. S. Abdalla, A Linear Piezoelectric Ultrasonic Motor Using a Single Flexural Vibrating Transducer for Electro Discharge System Industrial Applications, Int. J. Adv. Manuf. Technol. 45: 287–299, (2009).

DOI: 10.1007/s00170-009-1955-5

[15] He SY et al. Standing wave bi-directional linearly moving ultrasonic motor, IEEE trans. On Ultrasonics ferr. and freq. Control, vol. 45, no. 5, (1998).

DOI: 10.1109/58.726435

[16] J. Satonobu, and J. R. Friend. Travelling Wave Excitation in a Flexural Vibration Ring by Using a Torsional-Flexural Composite Transducer, IEEE Tran on Ultrasonics, Ferroelectrics and Frequency Control, Vol. 48, No. 4, (2001).

DOI: 10.1109/58.935722

[17] Tobias H., Jorg Wallaschek, Survey of the present state of the art of piezoelectric linear motors, Ultrasonics, 38, 37-40, (2000).

DOI: 10.1016/s0041-624x(99)00143-2

[18] Woo Seok Hwang and Hyun Chul Park. Finite element modelling piezoelectric sensors and actuators, AIAAJ, Vol. 31, No. 5, (1993).

[19] Yingxiang Liu, Weishan Chen, Junkao Liu, Shengjun Shi, A cylindrical standing wave ultrasonic motor using bending vibration transducer, Ultrasonics 51 527–531, (2011).

DOI: 10.1016/j.ultras.2010.12.007

[20] S. Ben-Yaakov, et al, A resonant driver for a piezoelectric motor, Power Conversion and intelligent Motor Conference, June, pp.173-178, (1999).

[21] Ueha S. and Tomikawa Y. Ultrasonic motors theory and applications, Clarendon press, Oxford, London, UK, (1993).

[22] Jacob Tal., Servomotors take piezoceramic transducers for a ride, Machine Design (ISSN 0024-9114), Penton Media, Inc., USA, (1999).
