Robust Design to Control the Chaos of Fold Mechanism with Clearance

Abstract:

With the increasing of web offset printing machines working speed, the nonlinear dynamics responses are more significant, even the fold mechanism with clearances appears some chaos phenomenon. Based on the dynamic model of fold mechanism, the nonlinear dynamics responses and the chaos movement in pair are studied. Used the performance parameters and dynamics response sensitivities as the goal values, the robust design model is established. By the robust design model, the nonlinear dynamic responses and chaos phenomenon can be under controlled in the same clearance degree. In this way, the performance of fold mechanism may be improved.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 153-157
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.153
• Online since: February 2013
• Authors: Ying Cai Yuan, Yan Li, Yi Ming Wang
• Keywords: Chaos, Clearance, Fold Mechanism, Robust Design

References

[1] Yuan Yingcai, Liu Yilun, Li Yan.Optimization Design of the Web Press's Fold Mechanism Based on Robustness.Advanced Material Research, Vol.174(2011):P277-281

[2] Chang Z.Y, Wang Y.X, Zhang C, Qiu M.X. Chaos phenomenon in mechanism with clearance. Mechanical Science and Technology, Vol.3 (1998),pp.345-347.(in Chinese)

[3] Earles S W E, Wu C L S. Motion analysis of a rigid-link mechanism with clearance at a bearing using Lagrangian mechanics and digital computation. Conference on Mechanisms, IME, Londond, England, 1972.

[4] Furuhashi T, Morita N, Matsuura M. Research on dynamics of four-bar linkage with clearances at turning pairs (including four reports) . Bulletin of the FSME, Vol.21( 1978),pp.518-523.

DOI: 10.1299/jsme1958.21.518

[5] Taguchi G. Taguchi on Robust Technology Development: Bring Quality Engineering Upstream. New York: ASME press, (1993)
